About
Learn what makes this product unique and why it’s right for you.
Compact yet powerful, the VigorSwitch Q60x is a silent, plug‑and‑play switch featuring 5 × 2.5 GbE ports and 1 × 10 GbE SFP+ uplink. With its durable metal casing, ultra‑low power consumption, and flexibility for desktop or wall mounting, it’s perfect for boosting bandwidth in small offices, high‑performance gaming setups, or home labs.
KEY FEATURES
| Feature | Description |
|---|---|
| 5 × 2.5 GbE Ports + 1 × 10 GbE SFP+ | Multi-gigabit support for fast LAN and high-speed uplink |
| Unmanaged Plug‑and‑Play | No configuration needed—just power and connect devices |
| Fanless & Silent | No moving parts and whisper-quiet operation |
| Low Power Consumption | Consumes only 4.85 W—efficient and eco‑friendly |
| Energy‑Efficient Ethernet (IEEE 802.3az) | Automatically reduces power on idle ports and short cables |
| Compact Metal Design | Sturdy, reliable, and thermally efficient enclosure |
| Wall Mountable | Flexible placement with included mounting options |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Ports | 5 × 10/100/1000/2500 Mbps RJ‑45; 1 × 1/2.5/10 GbE SFP+ uplink |
| Switching Capacity | 45 Gbps |
| Forwarding Rate | 33.5 Mpps (64‑byte frames) |
| MAC Address Table | 4 K entries |
| Packet Buffer Size | 8 Mbit |
| Jumbo Frame Support | Up to 12 KB |
| Loop Detection | Yes—helps prevent broadcast storms |
| Power Input & Consumption | AC 100–240 V @ 0.3 A, Max 4.85 W |
| Cooling | Passive cooling (fanless) |
| Physical Dimensions | 114 × 90 × 25 mm; weight approx. 250 g |
| Operating Environment | 0–45 °C; 10–90% RH non‑condensing |
| Storage Conditions | -40–70 °C; 5–95% RH non‑condensing |
Learn what makes this product unique and why it’s right for you.
Compact yet powerful, the VigorSwitch Q60x is a silent, plug‑and‑play switch featuring 5 × 2.5 GbE ports and 1 × 10 GbE SFP+ uplink. With its durable metal casing, ultra‑low power consumption, and flexibility for desktop or wall mounting, it’s perfect for boosting bandwidth in small offices, high‑performance gaming setups, or home labs.
KEY FEATURES
| Feature | Description |
|---|---|
| 5 × 2.5 GbE Ports + 1 × 10 GbE SFP+ | Multi-gigabit support for fast LAN and high-speed uplink |
| Unmanaged Plug‑and‑Play | No configuration needed—just power and connect devices |
| Fanless & Silent | No moving parts and whisper-quiet operation |
| Low Power Consumption | Consumes only 4.85 W—efficient and eco‑friendly |
| Energy‑Efficient Ethernet (IEEE 802.3az) | Automatically reduces power on idle ports and short cables |
| Compact Metal Design | Sturdy, reliable, and thermally efficient enclosure |
| Wall Mountable | Flexible placement with included mounting options |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Ports | 5 × 10/100/1000/2500 Mbps RJ‑45; 1 × 1/2.5/10 GbE SFP+ uplink |
| Switching Capacity | 45 Gbps |
| Forwarding Rate | 33.5 Mpps (64‑byte frames) |
| MAC Address Table | 4 K entries |
| Packet Buffer Size | 8 Mbit |
| Jumbo Frame Support | Up to 12 KB |
| Loop Detection | Yes—helps prevent broadcast storms |
| Power Input & Consumption | AC 100–240 V @ 0.3 A, Max 4.85 W |
| Cooling | Passive cooling (fanless) |
| Physical Dimensions | 114 × 90 × 25 mm; weight approx. 250 g |
| Operating Environment | 0–45 °C; 10–90% RH non‑condensing |
| Storage Conditions | -40–70 °C; 5–95% RH non‑condensing |
