The VigorSwitch P2100 is an 8-port Layer 2+/Layer 3 managed Gigabit switch with PoE+ on all ports and dual SFP uplinks. It’s ideal for SMBs requiring centralized management, IP camera surveillance orchestration, robust QoS, and network security in a compact rack-mountable form.
KEY FEATURES
| Feature | Description |
|---|---|
| 8 × PoE+ Gigabit Ports | Delivers up to 140 W total PoE budget for connected devices:contentReference[oaicite:1]{index=1} |
| 2 × SFP Uplinks | Gigabit fiber/fiber combo uplink flexibility:contentReference[oaicite:2]{index=2} |
| Advanced Management | Supports VigorACS, VigorConnect, SWM, Web UI, CLI, SNMP:contentReference[oaicite:3]{index=3} |
| Surveillance Integration | Auto-Voice/Surveillance VLAN, ONVIF camera management:contentReference[oaicite:4]{index=4} |
| Robust Security Features | 802.1x, ACL, DHCP snooping, IP Source Guard, IP Conflict Prevention, DoS defense, Storm/Loop control:contentReference[oaicite:5]{index=5} |
| Traffic Prioritization | 8 QoS queues with CoS, DSCP, SPQ/WRR support:contentReference[oaicite:6]{index=6} |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Switching Capacity & Throughput | 20 Gbps switching; 14.88 Mpps forwarding (64-byte):contentReference[oaicite:7]{index=7} |
| Buffer & MAC Table | 4.1 Mbit buffer, 8K MAC entries:contentReference[oaicite:8]{index=8} |
| Jumbo Frames | Up to 9 KB frame size:contentReference[oaicite:9]{index=9} |
| IPv4/IPv6, Routing, VLAN | Static & VLAN routing, DHCP server, supports 256 VLANs, QoS, IPv6 MLD snooping, IPv6 ACLs:contentReference[oaicite:10]{index=10} |
| Management & Diagnostics | Web UI, CLI, SSH, SNMP v1/2c/3, RMON, LLDP-MED, mail alerts, port mirroring, ping/cable test, syslog:contentReference[oaicite:11]{index=11} |
| Power & Physical | 140 W PoE budget, AC 100‑240 V, 164 W max consumption; 1U rack-mountable, 319×208×45 mm, 2.61 kg:contentReference[oaicite:12]{index=12} |
| Environmental | Operating Temp: 0–50 °C; Storage: –20–70 °C; Humidity: 10–90 % non-condensing:contentReference[oaicite:13]{index=13} |
| Technical Enhancements |
|
Learn what makes this product unique and why it’s right for you.
The VigorSwitch P2100 is an 8-port Layer 2+/Layer 3 managed Gigabit switch with PoE+ on all ports and dual SFP uplinks. It’s ideal for SMBs requiring centralized management, IP camera surveillance orchestration, robust QoS, and network security in a compact rack-mountable form.
KEY FEATURES
| Feature | Description |
|---|---|
| 8 × PoE+ Gigabit Ports | Delivers up to 140 W total PoE budget for connected devices:contentReference[oaicite:1]{index=1} |
| 2 × SFP Uplinks | Gigabit fiber/fiber combo uplink flexibility:contentReference[oaicite:2]{index=2} |
| Advanced Management | Supports VigorACS, VigorConnect, SWM, Web UI, CLI, SNMP:contentReference[oaicite:3]{index=3} |
| Surveillance Integration | Auto-Voice/Surveillance VLAN, ONVIF camera management:contentReference[oaicite:4]{index=4} |
| Robust Security Features | 802.1x, ACL, DHCP snooping, IP Source Guard, IP Conflict Prevention, DoS defense, Storm/Loop control:contentReference[oaicite:5]{index=5} |
| Traffic Prioritization | 8 QoS queues with CoS, DSCP, SPQ/WRR support:contentReference[oaicite:6]{index=6} |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Switching Capacity & Throughput | 20 Gbps switching; 14.88 Mpps forwarding (64-byte):contentReference[oaicite:7]{index=7} |
| Buffer & MAC Table | 4.1 Mbit buffer, 8K MAC entries:contentReference[oaicite:8]{index=8} |
| Jumbo Frames | Up to 9 KB frame size:contentReference[oaicite:9]{index=9} |
| IPv4/IPv6, Routing, VLAN | Static & VLAN routing, DHCP server, supports 256 VLANs, QoS, IPv6 MLD snooping, IPv6 ACLs:contentReference[oaicite:10]{index=10} |
| Management & Diagnostics | Web UI, CLI, SSH, SNMP v1/2c/3, RMON, LLDP-MED, mail alerts, port mirroring, ping/cable test, syslog:contentReference[oaicite:11]{index=11} |
| Power & Physical | 140 W PoE budget, AC 100‑240 V, 164 W max consumption; 1U rack-mountable, 319×208×45 mm, 2.61 kg:contentReference[oaicite:12]{index=12} |
| Environmental | Operating Temp: 0–50 °C; Storage: –20–70 °C; Humidity: 10–90 % non-condensing:contentReference[oaicite:13]{index=13} |
| Technical Enhancements |
|
VigorSwitch P2100
- Regular price
- $350.00
- Sale price
- $350.00
