About
The DrayTek VigorSwitch G2282x is a powerful Layer 2+ managed switch designed for enterprise networks requiring high-speed, reliable, and scalable performance. It features 24 Gigabit RJ-45 ports and 4 10G SFP+ uplink ports, ideal for connecting servers, core switches, or high-throughput uplinks. The switch supports robust VLAN, QoS, and security controls and is easily managed via VigorACS, CLI, or DrayTek routers.
KEY FEATURES
| Feature | Description |
|---|---|
| 24-Port Gigabit Ethernet | 24 x 10/100/1000Mbps RJ-45 ports for LAN connectivity |
| 4 x 10G SFP+ Uplink Ports | Ideal for high-speed uplinks, servers, or fiber links |
| Layer 2+ Management | Supports VLAN, static routing, port mirroring, IGMP, and more |
| Advanced Security | 802.1X authentication, ACL, DoS protection, and storm control |
| Quality of Service (QoS) | Traffic prioritization using 802.1p and DSCP standards |
| Centralized Management | Manage through VigorACS, web GUI, CLI, or DrayTek Router Switch Controller |
| Fan Cooled | Efficient thermal management with built-in fans |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Switch Type | Managed Layer 2+ Gigabit Switch |
| Ethernet Ports | 24 x 10/100/1000 Mbps RJ-45 |
| SFP+ Ports | 4 x 10G SFP+ (uplink/fiber) |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.23 Mpps |
| MAC Address Table | 16K MAC addresses |
| VLAN Support | 802.1Q VLAN, up to 256 VLANs |
| QoS | 8 priority queues per port, 802.1p, DSCP |
| Static Routing | Supported (Layer 2+) |
| Management Interface | Web GUI, CLI, SNMP, VigorACS, Router Controller |
| Power Supply | Internal AC power supply |
| Power Consumption | Max. 32W |
| Cooling | Fan cooled |
| Dimensions | 441 x 207 x 44 mm |
| Weight | Approx. 3.0 kg |
| Operating Temperature | 0°C to 50°C |
The DrayTek VigorSwitch G2282x is a powerful Layer 2+ managed switch designed for enterprise networks requiring high-speed, reliable, and scalable performance. It features 24 Gigabit RJ-45 ports and 4 10G SFP+ uplink ports, ideal for connecting servers, core switches, or high-throughput uplinks. The switch supports robust VLAN, QoS, and security controls and is easily managed via VigorACS, CLI, or DrayTek routers.
KEY FEATURES
| Feature | Description |
|---|---|
| 24-Port Gigabit Ethernet | 24 x 10/100/1000Mbps RJ-45 ports for LAN connectivity |
| 4 x 10G SFP+ Uplink Ports | Ideal for high-speed uplinks, servers, or fiber links |
| Layer 2+ Management | Supports VLAN, static routing, port mirroring, IGMP, and more |
| Advanced Security | 802.1X authentication, ACL, DoS protection, and storm control |
| Quality of Service (QoS) | Traffic prioritization using 802.1p and DSCP standards |
| Centralized Management | Manage through VigorACS, web GUI, CLI, or DrayTek Router Switch Controller |
| Fan Cooled | Efficient thermal management with built-in fans |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Switch Type | Managed Layer 2+ Gigabit Switch |
| Ethernet Ports | 24 x 10/100/1000 Mbps RJ-45 |
| SFP+ Ports | 4 x 10G SFP+ (uplink/fiber) |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.23 Mpps |
| MAC Address Table | 16K MAC addresses |
| VLAN Support | 802.1Q VLAN, up to 256 VLANs |
| QoS | 8 priority queues per port, 802.1p, DSCP |
| Static Routing | Supported (Layer 2+) |
| Management Interface | Web GUI, CLI, SNMP, VigorACS, Router Controller |
| Power Supply | Internal AC power supply |
| Power Consumption | Max. 32W |
| Cooling | Fan cooled |
| Dimensions | 441 x 207 x 44 mm |
| Weight | Approx. 3.0 kg |
| Operating Temperature | 0°C to 50°C |
