About
Learn what makes this product unique and why it’s right for you.
The DrayTek VigorAP 805 is a compact and reliable dual-band wireless access point built for business networks. Supporting Wi-Fi 5 (802.11ac), it delivers high-performance wireless connectivity and is ideal for extending wireless coverage in office environments. With VLAN support, multiple SSIDs, PoE power, and centralized management compatibility, it's designed for scalable and secure deployments.
KEY FEATURES
| Dual-Band Wi-Fi 5 | Concurrent 2.4GHz & 5GHz operation for wider coverage and less congestion |
| 867 Mbps on 5GHz | High-speed wireless performance for demanding applications |
| Multiple SSIDs with VLAN | Supports up to 8 SSIDs for guest/staff or department separation |
| Central Management Support | Easily managed via DrayTek VigorACS or compatible routers |
| WPA3 Security | Enhanced wireless security for modern networks |
| Mesh Wi-Fi Ready | Works in Mesh setups with other DrayTek APs |
| PoE Powered | Simplifies installation; no need for nearby power outlets |
| Compact Design | Wall or ceiling mountable for discreet deployment |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Wireless Standard | Dual-band 802.11ac Wave 2 (Wi-Fi 5) |
| Frequency Bands | 2.4 GHz and 5 GHz concurrent |
| Wireless Speed | Up to 300 Mbps (2.4 GHz) + up to 867 Mbps (5 GHz) |
| Wi-Fi Features | MU-MIMO, Band Steering, Airtime Fairness |
| SSIDs | Up to 8 SSIDs (4 per band) |
| VLAN Support | 802.1q VLAN tagging per SSID |
| Security Protocols | WPA2-Personal, WPA2-Enterprise, WPA3-Personal, MAC address filtering |
| Wireless Management | Wireless client limit, Rogue AP detection, Wireless isolation |
| Mesh Support | Yes (DrayTek Mesh network compatible) |
| Ethernet Ports | 1 x Gigabit Ethernet (RJ-45) |
| PoE Support | IEEE 802.3af PoE (Power over Ethernet) |
| Power Supply | 12V DC (optional) or PoE (802.3af) |
| Antenna | Internal high-gain antennas |
| Management Options | Web GUI, CLI (Telnet/SSH), TR-069, VigorACS, Central AP Management |
| Mounting Options | Wall or ceiling mountable |
| Dimensions | Approx. 135 x 90 x 28 mm |
| Weight | Approx. 200 grams |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity | 10% to 90% non-condensing |
Learn what makes this product unique and why it’s right for you.
The DrayTek VigorAP 805 is a compact and reliable dual-band wireless access point built for business networks. Supporting Wi-Fi 5 (802.11ac), it delivers high-performance wireless connectivity and is ideal for extending wireless coverage in office environments. With VLAN support, multiple SSIDs, PoE power, and centralized management compatibility, it's designed for scalable and secure deployments.
KEY FEATURES
| Dual-Band Wi-Fi 5 | Concurrent 2.4GHz & 5GHz operation for wider coverage and less congestion |
| 867 Mbps on 5GHz | High-speed wireless performance for demanding applications |
| Multiple SSIDs with VLAN | Supports up to 8 SSIDs for guest/staff or department separation |
| Central Management Support | Easily managed via DrayTek VigorACS or compatible routers |
| WPA3 Security | Enhanced wireless security for modern networks |
| Mesh Wi-Fi Ready | Works in Mesh setups with other DrayTek APs |
| PoE Powered | Simplifies installation; no need for nearby power outlets |
| Compact Design | Wall or ceiling mountable for discreet deployment |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Wireless Standard | Dual-band 802.11ac Wave 2 (Wi-Fi 5) |
| Frequency Bands | 2.4 GHz and 5 GHz concurrent |
| Wireless Speed | Up to 300 Mbps (2.4 GHz) + up to 867 Mbps (5 GHz) |
| Wi-Fi Features | MU-MIMO, Band Steering, Airtime Fairness |
| SSIDs | Up to 8 SSIDs (4 per band) |
| VLAN Support | 802.1q VLAN tagging per SSID |
| Security Protocols | WPA2-Personal, WPA2-Enterprise, WPA3-Personal, MAC address filtering |
| Wireless Management | Wireless client limit, Rogue AP detection, Wireless isolation |
| Mesh Support | Yes (DrayTek Mesh network compatible) |
| Ethernet Ports | 1 x Gigabit Ethernet (RJ-45) |
| PoE Support | IEEE 802.3af PoE (Power over Ethernet) |
| Power Supply | 12V DC (optional) or PoE (802.3af) |
| Antenna | Internal high-gain antennas |
| Management Options | Web GUI, CLI (Telnet/SSH), TR-069, VigorACS, Central AP Management |
| Mounting Options | Wall or ceiling mountable |
| Dimensions | Approx. 135 x 90 x 28 mm |
| Weight | Approx. 200 grams |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity | 10% to 90% non-condensing |
VigorAP 805
- Regular price
- $150.00
- Sale price
- $150.00
- Regular price
-
Couldn't load pickup availability
