About
Learn what makes this product unique and why it’s right for you.
The VigorAP 1062C is DrayTek's flagship Wi-Fi 6 access point, designed for ultra-fast and reliable wireless connectivity in high-density environments. It features tri-band simultaneous operation, two 2.5GbE LAN ports, and supports up to 8 spatial streams for superior throughput and coverage. Ideal for business, education, and hospitality deployments requiring robust performance and centralized management.
KEY FEATURES
| Feature | Description |
|---|---|
| Tri-Band Wi-Fi 6 | Simultaneous 2.4GHz, 5GHz-1, and 5GHz-2 operation for optimal device distribution |
| AX7800 Speeds | Up to 4800 Mbps (5GHz-1), 2400 Mbps (5GHz-2), and 574 Mbps (2.4GHz) |
| 8 Spatial Streams | Greater throughput and more simultaneous connections |
| Dual 2.5GbE Ports | Two 2.5 Gigabit LAN ports for high-speed uplink and local bridging |
| PoE++ Support | Powered via 802.3bt (PoE++) for greater power and simplified installation |
| Mesh Networking | DrayTek Mesh system support for seamless roaming and scalability |
| WPA3 Security | Modern encryption standard for secure wireless access |
| Up to 12 SSIDs | Supports 4 SSIDs per band with VLAN tagging for network segmentation |
| Advanced Wireless Features | OFDMA, MU-MIMO, Band Steering, Airtime Fairness, BSS Coloring |
| Central Management | Managed via DrayTek VigorACS or compatible DrayTek routers |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Wireless Standard | 802.11ax (Wi-Fi 6), Tri-Band |
| Frequency Bands | 2.4GHz, 5GHz-1, 5GHz-2 |
| Wireless Speed | AX7800 total: 4800 Mbps + 2400 Mbps + 574 Mbps |
| Spatial Streams | 8x8 MU-MIMO |
| Wi-Fi Features | OFDMA, MU-MIMO, BSS Coloring, Band Steering, Airtime Fairness |
| SSID Support | Up to 12 SSIDs (4 per band) |
| VLAN Support | 802.1q VLAN tagging per SSID |
| Security Protocols | WPA2/WPA3-Personal/Enterprise, MAC filtering, Isolation |
| Ethernet Ports | 2 x 2.5GbE LAN (RJ-45) |
| PoE Support | IEEE 802.3bt (PoE++) |
| Power Input | Via PoE++ or optional 12V DC adapter |
| Management Interfaces | Web GUI, CLI (Telnet/SSH), TR-069, VigorACS, DrayTek AP Management |
| Mesh Support | Yes – DrayTek Mesh compatible |
| Mounting Options | Ceiling mountable (kit included) |
| Dimensions | 240 x 240 x 45 mm |
| Weight | Approx. 800 grams |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity | 10% to 90% non-condensing |
Learn what makes this product unique and why it’s right for you.
The VigorAP 1062C is DrayTek's flagship Wi-Fi 6 access point, designed for ultra-fast and reliable wireless connectivity in high-density environments. It features tri-band simultaneous operation, two 2.5GbE LAN ports, and supports up to 8 spatial streams for superior throughput and coverage. Ideal for business, education, and hospitality deployments requiring robust performance and centralized management.
KEY FEATURES
| Feature | Description |
|---|---|
| Tri-Band Wi-Fi 6 | Simultaneous 2.4GHz, 5GHz-1, and 5GHz-2 operation for optimal device distribution |
| AX7800 Speeds | Up to 4800 Mbps (5GHz-1), 2400 Mbps (5GHz-2), and 574 Mbps (2.4GHz) |
| 8 Spatial Streams | Greater throughput and more simultaneous connections |
| Dual 2.5GbE Ports | Two 2.5 Gigabit LAN ports for high-speed uplink and local bridging |
| PoE++ Support | Powered via 802.3bt (PoE++) for greater power and simplified installation |
| Mesh Networking | DrayTek Mesh system support for seamless roaming and scalability |
| WPA3 Security | Modern encryption standard for secure wireless access |
| Up to 12 SSIDs | Supports 4 SSIDs per band with VLAN tagging for network segmentation |
| Advanced Wireless Features | OFDMA, MU-MIMO, Band Steering, Airtime Fairness, BSS Coloring |
| Central Management | Managed via DrayTek VigorACS or compatible DrayTek routers |
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Wireless Standard | 802.11ax (Wi-Fi 6), Tri-Band |
| Frequency Bands | 2.4GHz, 5GHz-1, 5GHz-2 |
| Wireless Speed | AX7800 total: 4800 Mbps + 2400 Mbps + 574 Mbps |
| Spatial Streams | 8x8 MU-MIMO |
| Wi-Fi Features | OFDMA, MU-MIMO, BSS Coloring, Band Steering, Airtime Fairness |
| SSID Support | Up to 12 SSIDs (4 per band) |
| VLAN Support | 802.1q VLAN tagging per SSID |
| Security Protocols | WPA2/WPA3-Personal/Enterprise, MAC filtering, Isolation |
| Ethernet Ports | 2 x 2.5GbE LAN (RJ-45) |
| PoE Support | IEEE 802.3bt (PoE++) |
| Power Input | Via PoE++ or optional 12V DC adapter |
| Management Interfaces | Web GUI, CLI (Telnet/SSH), TR-069, VigorACS, DrayTek AP Management |
| Mesh Support | Yes – DrayTek Mesh compatible |
| Mounting Options | Ceiling mountable (kit included) |
| Dimensions | 240 x 240 x 45 mm |
| Weight | Approx. 800 grams |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity | 10% to 90% non-condensing |
VigorAP 1062C
- Regular price
- $550.00
- Sale price
- $550.00
- Regular price
-
Couldn't load pickup availability
