About
Learn what makes this product unique and why it’s right for you.
The InSight S485 is an 8MP (4K) turret camera offering full-color imaging 24/7. It features advanced people and vehicle analytics, smart detection, active defense with two-way audio, and robust weatherproof design, making it ideal for high-resolution surveillance in any environment.
FEATURES
- 4K (8MP) Ultra HD with 24-hour full-color imaging for clear surveillance day and night
- People & Vehicle Analytics for accurate monitoring and alerts
- Human & Vehicle Classification to reduce false alarms
- Smart Detection and Video Enhancement Technology for clearer, enhanced images
- Active Defense with Two-Way Audio for instant communication and deterrence
- IP67 Waterproof protection for reliable outdoor use
- H.265+ Compression Technology for efficient video storage
- Flexible power options: 12V DC or PoE
SPECIFICATION
| Category | Details |
|---|---|
| Camera | 1/2.7” Progressive Scan CMOS, 1/3 to 1/10000 s shutter, 0.005 Lux (0 Lux with IR/White light), IR Cut Filter, Max Resolution 3840×2160 |
| Lens | Fixed Focal Lens, 2.8 mm / 4 mm, F1.6, FOV: 2.8mm (H:111.4°, V:58.8°, D:134°), 4mm (H:91.5°, V:46.1°, D:109.6°), DORI distance up to 107 m |
| Illuminator | IR LEDs ×4 (30 m, 850 nm), White LEDs ×4 (30 m), Auto/Scheduled/Always On/Off |
| Video | Main Stream: Up to 3840×2160, Sub-Stream: Up to 848×480, H.265+/H.265/H.264+/H.264, Bit rate: 256 Kbps–8 Mbps (Main), 64–512 Kbps (Sub), WDR 120 dB |
| Image Features | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, DWDR, White Balance, HLC, BLC, 3D DNR, SmartIR, Privacy Mask up to 4, ROI 1 |
| Audio | Two-way audio, Built-in microphone & speaker, G.711 alaw, 64 Kbps, Environment noise filtering |
| Network | TCP/IP, HTTP, HTTPS, RTSP, DHCP, DNS, NTP, FTP/SFTP, IPv4/IPv6, ONVIF, Open API, 3 Main & 3 Sub-streams, Cloud support, Security: Password, HTTPS, IP filter, Digest authentication |
| Smart & Basic Events | Intrusion, Line Crossing, Region Enter/Exit, Object Abandoned/Removed, Loitering, People & Vehicle Detection, Abnormal Sound, Scene Change, Motion Detection with Human & Vehicle Classification, Alarm: recording, push, audible warning, white light flashing, People & Vehicle Analytics |
| Interfaces & Storage | 1 RJ45 10/100M Ethernet, PoE, MicroSD slot up to 512 GB, Reset button |
| General | Metal body, 0.48 kg, Dimensions 111×111×83.7 mm, Operating Temp: -30°C to 60°C, Storage Temp: -40°C to 60°C, Humidity ≤95% non-condensing, IP67, Power: 12V DC 11.5 W / PoE 12.5 W, Certifications: CE, NTRA, VCCI, KC, BSMI, FCC, IC |
Learn what makes this product unique and why it’s right for you.
The InSight S485 is an 8MP (4K) turret camera offering full-color imaging 24/7. It features advanced people and vehicle analytics, smart detection, active defense with two-way audio, and robust weatherproof design, making it ideal for high-resolution surveillance in any environment.
FEATURES
- 4K (8MP) Ultra HD with 24-hour full-color imaging for clear surveillance day and night
- People & Vehicle Analytics for accurate monitoring and alerts
- Human & Vehicle Classification to reduce false alarms
- Smart Detection and Video Enhancement Technology for clearer, enhanced images
- Active Defense with Two-Way Audio for instant communication and deterrence
- IP67 Waterproof protection for reliable outdoor use
- H.265+ Compression Technology for efficient video storage
- Flexible power options: 12V DC or PoE
SPECIFICATION
| Category | Details |
|---|---|
| Camera | 1/2.7” Progressive Scan CMOS, 1/3 to 1/10000 s shutter, 0.005 Lux (0 Lux with IR/White light), IR Cut Filter, Max Resolution 3840×2160 |
| Lens | Fixed Focal Lens, 2.8 mm / 4 mm, F1.6, FOV: 2.8mm (H:111.4°, V:58.8°, D:134°), 4mm (H:91.5°, V:46.1°, D:109.6°), DORI distance up to 107 m |
| Illuminator | IR LEDs ×4 (30 m, 850 nm), White LEDs ×4 (30 m), Auto/Scheduled/Always On/Off |
| Video | Main Stream: Up to 3840×2160, Sub-Stream: Up to 848×480, H.265+/H.265/H.264+/H.264, Bit rate: 256 Kbps–8 Mbps (Main), 64–512 Kbps (Sub), WDR 120 dB |
| Image Features | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, DWDR, White Balance, HLC, BLC, 3D DNR, SmartIR, Privacy Mask up to 4, ROI 1 |
| Audio | Two-way audio, Built-in microphone & speaker, G.711 alaw, 64 Kbps, Environment noise filtering |
| Network | TCP/IP, HTTP, HTTPS, RTSP, DHCP, DNS, NTP, FTP/SFTP, IPv4/IPv6, ONVIF, Open API, 3 Main & 3 Sub-streams, Cloud support, Security: Password, HTTPS, IP filter, Digest authentication |
| Smart & Basic Events | Intrusion, Line Crossing, Region Enter/Exit, Object Abandoned/Removed, Loitering, People & Vehicle Detection, Abnormal Sound, Scene Change, Motion Detection with Human & Vehicle Classification, Alarm: recording, push, audible warning, white light flashing, People & Vehicle Analytics |
| Interfaces & Storage | 1 RJ45 10/100M Ethernet, PoE, MicroSD slot up to 512 GB, Reset button |
| General | Metal body, 0.48 kg, Dimensions 111×111×83.7 mm, Operating Temp: -30°C to 60°C, Storage Temp: -40°C to 60°C, Humidity ≤95% non-condensing, IP67, Power: 12V DC 11.5 W / PoE 12.5 W, Certifications: CE, NTRA, VCCI, KC, BSMI, FCC, IC |
VIGI 8MP Full-Color Turret Network Camera
- Regular price
- $236.61
- Sale price
- $236.61
- Regular price
-
$239.00
Couldn't load pickup availability
