The Ubiquiti EdgeSwitch 8 150W is a compact, fully managed Gigabit switch that delivers robust performance and intelligent switching for growing networks. It features 8 Gigabit Ethernet ports with 802.3af/at PoE+ support and two SFP ports for fiber uplinks, offering a total PoE budget of 150 watts. The EdgeSwitch provides advanced Layer 2 switching capabilities and Layer 3 routing features, making it ideal for small business or enterprise deployments where efficient power delivery and high-performance connectivity are required.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model | EdgeSwitch 8 150W |
| Ports | 8 x Gigabit RJ45 Ports, 2 x SFP Ports |
| PoE Support | 802.3af/at PoE+, 24V Passive PoE |
| Total PoE Budget | 150W |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.88 Mpps |
| Processor | Dual-Core 500 MHz, MIPS64 |
| System Memory | 256 MB DDR3 |
| Flash Storage | 256 MB |
| Layer Support | Layer 2 and Layer 3 |
| VLAN Support | 802.1Q VLAN, Voice VLAN |
| Management Interface | Web UI, CLI, SSH, Telnet, SNMP |
| Jumbo Frame Support | Yes (9216 bytes) |
| Power Input | AC 100–240V, 2A Max, 50/60 Hz |
| Max Power Consumption | 150W |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10% to 90% Noncondensing |
| Dimensions | 204 x 43 x 235 mm |
| Weight | 1.70 kg |
| Mounting | Desktop or Wall-Mount |
The Ubiquiti EdgeSwitch 8 150W is a compact, fully managed Gigabit switch that delivers robust performance and intelligent switching for growing networks. It features 8 Gigabit Ethernet ports with 802.3af/at PoE+ support and two SFP ports for fiber uplinks, offering a total PoE budget of 150 watts. The EdgeSwitch provides advanced Layer 2 switching capabilities and Layer 3 routing features, making it ideal for small business or enterprise deployments where efficient power delivery and high-performance connectivity are required.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model | EdgeSwitch 8 150W |
| Ports | 8 x Gigabit RJ45 Ports, 2 x SFP Ports |
| PoE Support | 802.3af/at PoE+, 24V Passive PoE |
| Total PoE Budget | 150W |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.88 Mpps |
| Processor | Dual-Core 500 MHz, MIPS64 |
| System Memory | 256 MB DDR3 |
| Flash Storage | 256 MB |
| Layer Support | Layer 2 and Layer 3 |
| VLAN Support | 802.1Q VLAN, Voice VLAN |
| Management Interface | Web UI, CLI, SSH, Telnet, SNMP |
| Jumbo Frame Support | Yes (9216 bytes) |
| Power Input | AC 100–240V, 2A Max, 50/60 Hz |
| Max Power Consumption | 150W |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10% to 90% Noncondensing |
| Dimensions | 204 x 43 x 235 mm |
| Weight | 1.70 kg |
| Mounting | Desktop or Wall-Mount |
Ubiquiti EdgeSwitch 8 Port 150W
- Regular price
- $430.00
- Sale price
- $430.00
- Regular price
-
$435.00
Couldn't load pickup availability
