About
The Rocket 2AC Prism combines Ubiquiti’s airMAX ac radio architecture with airPrism active RF filtering to improve performance in dense environments. It is a 2.4 GHz base station radio optimized for both point‑to‑multipoint (PtMP) and point‑to‑point (PtP) deployments. It supports GPS synchronization, channel flexibility, and is built to handle interference with high selectivity. The form factor allows it to be directly mounted with airMAX sector or dish antennas for integrated deployments.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model / Series | airMAX Rocket 2AC Prism (R2AC‑PRISM) |
| Wireless / Technology | airMAX ac; airPrism active RF filtering |
| Operating Frequency | 2.4 GHz band — 2412 to 2472 MHz (worldwide) |
| Management / Secondary Radio Band | 5150 – 5250 MHz (for setup/monitoring in select regions) |
| Networking Interface | 1 × Gigabit Ethernet (10/100/1000 RJ‑45) |
| Power / PoE | 24 V, 0.5 A passive PoE (pairs 4,5+; 7,8 return) |
| Supported Voltage Range | Approximately 20 – 27 V DC |
| Max Power Consumption | ~ 9.5 W |
| RF Connectors | 2 × RP‑SMA (waterproof) for antennas; plus 1 × GPS (waterproof) |
| Enclosure / Housing | Die‑cast aluminum, white powder coating |
| Dimensions | 88 × 40 × 230 mm (3.5 × 1.6 × 9.1 in) |
| Weight | ~ 400 g |
| Operating Temperature | −40 °C to +80 °C |
| Operating Humidity | 5% to 95% non‑condensing |
| ESD / Surge Protection | ± 24 kV (air/contact) on Ethernet |
| Shock / Vibration | Meets ETSI 300‑019‑1.4 standards |
| Modes / Features | Access Point, Station; automatic/manual Tx power, distance ACK timing, GPS sync, spectral analysis |
| Channel Bandwidths | 10 / 20 / 40 MHz |
| Security / Encryption | WPA2 (AES) |
| Certifications | CE, FCC, IC |
The Rocket 2AC Prism combines Ubiquiti’s airMAX ac radio architecture with airPrism active RF filtering to improve performance in dense environments. It is a 2.4 GHz base station radio optimized for both point‑to‑multipoint (PtMP) and point‑to‑point (PtP) deployments. It supports GPS synchronization, channel flexibility, and is built to handle interference with high selectivity. The form factor allows it to be directly mounted with airMAX sector or dish antennas for integrated deployments.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model / Series | airMAX Rocket 2AC Prism (R2AC‑PRISM) |
| Wireless / Technology | airMAX ac; airPrism active RF filtering |
| Operating Frequency | 2.4 GHz band — 2412 to 2472 MHz (worldwide) |
| Management / Secondary Radio Band | 5150 – 5250 MHz (for setup/monitoring in select regions) |
| Networking Interface | 1 × Gigabit Ethernet (10/100/1000 RJ‑45) |
| Power / PoE | 24 V, 0.5 A passive PoE (pairs 4,5+; 7,8 return) |
| Supported Voltage Range | Approximately 20 – 27 V DC |
| Max Power Consumption | ~ 9.5 W |
| RF Connectors | 2 × RP‑SMA (waterproof) for antennas; plus 1 × GPS (waterproof) |
| Enclosure / Housing | Die‑cast aluminum, white powder coating |
| Dimensions | 88 × 40 × 230 mm (3.5 × 1.6 × 9.1 in) |
| Weight | ~ 400 g |
| Operating Temperature | −40 °C to +80 °C |
| Operating Humidity | 5% to 95% non‑condensing |
| ESD / Surge Protection | ± 24 kV (air/contact) on Ethernet |
| Shock / Vibration | Meets ETSI 300‑019‑1.4 standards |
| Modes / Features | Access Point, Station; automatic/manual Tx power, distance ACK timing, GPS sync, spectral analysis |
| Channel Bandwidths | 10 / 20 / 40 MHz |
| Security / Encryption | WPA2 (AES) |
| Certifications | CE, FCC, IC |
Ubiquiti airMAX Rocket 2AC Prism (R2AC-PRISM)
- Regular price
- $376.25
- Sale price
- $376.25
- Regular price
-
$442.75
Couldn't load pickup availability
