About

Learn what makes this product unique and why it’s right for you.

SX6632YF is a high-performance Layer 3 aggregation switch designed for enterprise and data center networks. It offers 26 10G SFP+ ports and 6 25G SFP28 slots for flexible, high-speed connectivity. With advanced Layer 3 routing, robust security, and stacking capabilities, the SX6632YF integrates seamlessly into Omada SDN networks, delivering scalable, reliable, and efficient network management.





TECHNICAL SPECIFICATION

Category  Details
Model SX6632YF
Ports 26 × 10G SFP+ slots, 6 × 25G SFP28 slots, RJ45/Type C USB console port, management port, 2 × USB 3.0 ports
Switching Capacity 1.28 Tbps
Forwarding Rate 952.4 Mpps
Layer Layer 3 (L3) Managed
Form Factor 1U 19-inch rack-mountable steel case
Stacking Supports stackable up to 4 units
Routing Protocols Static Routing, RIP, OSPF, BGP, VRRP, ECMP, PIM-DM
Features Integration with Omada SDN Controller, ERPS, DHCP Server, DHCP Relay, RSPAN, QinQ, OAM, sFlow, DDM, 802.1Q VLAN, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1X, RADIUS/TACACS+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6, Hot swappable fan and power supply modules
Security 802.1X, DHCP Snooping, IP Source Guard, DoS Protection
Power Supply Dual, hot-swappable, 400W each
Dimensions (WxDxH) 440 x 320 x 44 mm (1U Rackmount)
Operating Temperature 0°C to 45°C
Weight Approx. 5.6 kg
Learn what makes this product unique and why it’s right for you.

SX6632YF is a high-performance Layer 3 aggregation switch designed for enterprise and data center networks. It offers 26 10G SFP+ ports and 6 25G SFP28 slots for flexible, high-speed connectivity. With advanced Layer 3 routing, robust security, and stacking capabilities, the SX6632YF integrates seamlessly into Omada SDN networks, delivering scalable, reliable, and efficient network management.





TECHNICAL SPECIFICATION

Category  Details
Model SX6632YF
Ports 26 × 10G SFP+ slots, 6 × 25G SFP28 slots, RJ45/Type C USB console port, management port, 2 × USB 3.0 ports
Switching Capacity 1.28 Tbps
Forwarding Rate 952.4 Mpps
Layer Layer 3 (L3) Managed
Form Factor 1U 19-inch rack-mountable steel case
Stacking Supports stackable up to 4 units
Routing Protocols Static Routing, RIP, OSPF, BGP, VRRP, ECMP, PIM-DM
Features Integration with Omada SDN Controller, ERPS, DHCP Server, DHCP Relay, RSPAN, QinQ, OAM, sFlow, DDM, 802.1Q VLAN, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1X, RADIUS/TACACS+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6, Hot swappable fan and power supply modules
Security 802.1X, DHCP Snooping, IP Source Guard, DoS Protection
Power Supply Dual, hot-swappable, 400W each
Dimensions (WxDxH) 440 x 320 x 44 mm (1U Rackmount)
Operating Temperature 0°C to 45°C
Weight Approx. 5.6 kg

SX6632YF - Omada 26-Port 10G Stackable L3 Managed Aggregation Switch with 6 25G Slots

$5,999.00
