About
The TP-Link Omada SG3452XP is a 48-Port Gigabit L2+ Managed Switch with full PoE+ support, designed for scalable business networks requiring high bandwidth and secure management. Featuring 48× PoE+ Gigabit ports, 4× 10G SFP+ uplink slots, and a 500 W PoE budget, it’s ideal for powering access points, IP cameras, and VoIP phones. The switch is rack-mountable, housed in a durable steel case, and integrates seamlessly with the Omada SDN Controller for centralized cloud or local management.
It supports a rich set of features including Static Routing, OAM, DDM, sFlow, VLAN (802.1Q/QinQ), STP/RSTP/MSTP, IGMP Snooping, QoS (802.1p/DSCP), ACLs, 802.1X, RADIUS/TACACS+ Authentication, LACP, CLI, SNMP, Dual Image/Config, and full IPv6 support.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Product Name | Omada SG3452XP – 48-Port PoE+ Gigabit L2+ Managed Switch with 4× 10G SFP+ Slots |
| Ports | 48 × 10/100/1000 Mbps PoE+ RJ45 Ports 4 × 10G SFP+ Slots 1 × RJ45 Console Port 1 × Micro-USB Console Port |
| PoE Standard | IEEE 802.3af/at (PoE+) |
| PoE Budget | 500 W total PoE power budget Up to 30 W per PoE+ port |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.9 Mpps |
| MAC Address Table | 16K entries |
| Buffer / Jumbo Frame | Packet Buffer: 12 Mbit Jumbo Frame: 9 KB |
| Management | Omada SDN (Cloud/Software/Hardware Controller) Web UI, CLI (RJ45 & USB Console), Telnet, SSH SNMP v1/v2c/v3, RMON, Syslog, Dual Image & Config |
| Layer 2+ Features | Static Routing (IPv4/IPv6), OAM, DDM, sFlow 802.1Q VLAN, QinQ, Private VLAN STP/RSTP/MSTP, Loopback Detection |
| Security & Authentication | 802.1X (Port-Based & MAC-Based), Radius, TACACS+ DHCP Snooping, ARP Inspection, DoS Defense IP-MAC-Port Binding, Port Security |
| Quality of Service (QoS) | 8 Priority Queues, 802.1p, DSCP, Rate Limiting Scheduling: SP, WRR, SP+WRR |
| Multicast Support | IGMP Snooping v1/v2/v3 MLD Snooping v1/v2 IGMP Authentication, Multicast VLAN (MVR) |
| IPv6 Support | Dual Stack IPv4/IPv6 IPv6 ACL, IPv6 Static Routing MLD Snooping, IPv6 Neighbor Discovery |
| Link Aggregation | Supports LACP & Static LAG Up to 26 Aggregation Groups, 8 Ports per Group |
| Enclosure | 1U 19-inch Rack-Mountable Steel Case |
| Cooling | 3 × Active Cooling Fans |
| Power Supply | AC 100–240 V ~ 50/60 Hz |
| Power Consumption | Max: 635.7 W (with PoE load) Typical: 49.19 W (without PoE) |
| Dimensions | 440 × 330 × 44 mm (17.3 × 13.0 × 1.7 in) |
| Operating Environment | Temperature: 0–40°C (Operating), -40–70°C (Storage) Humidity: 10–90% RH (non-condensing) |
| Certifications | CE, FCC, RoHS |
| Package Contents | SG3452XP Switch, Power Cord, Rack Mount Kit, Rubber Feet, Quick Installation Guide |
The TP-Link Omada SG3452XP is a 48-Port Gigabit L2+ Managed Switch with full PoE+ support, designed for scalable business networks requiring high bandwidth and secure management. Featuring 48× PoE+ Gigabit ports, 4× 10G SFP+ uplink slots, and a 500 W PoE budget, it’s ideal for powering access points, IP cameras, and VoIP phones. The switch is rack-mountable, housed in a durable steel case, and integrates seamlessly with the Omada SDN Controller for centralized cloud or local management.
It supports a rich set of features including Static Routing, OAM, DDM, sFlow, VLAN (802.1Q/QinQ), STP/RSTP/MSTP, IGMP Snooping, QoS (802.1p/DSCP), ACLs, 802.1X, RADIUS/TACACS+ Authentication, LACP, CLI, SNMP, Dual Image/Config, and full IPv6 support.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Product Name | Omada SG3452XP – 48-Port PoE+ Gigabit L2+ Managed Switch with 4× 10G SFP+ Slots |
| Ports | 48 × 10/100/1000 Mbps PoE+ RJ45 Ports 4 × 10G SFP+ Slots 1 × RJ45 Console Port 1 × Micro-USB Console Port |
| PoE Standard | IEEE 802.3af/at (PoE+) |
| PoE Budget | 500 W total PoE power budget Up to 30 W per PoE+ port |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.9 Mpps |
| MAC Address Table | 16K entries |
| Buffer / Jumbo Frame | Packet Buffer: 12 Mbit Jumbo Frame: 9 KB |
| Management | Omada SDN (Cloud/Software/Hardware Controller) Web UI, CLI (RJ45 & USB Console), Telnet, SSH SNMP v1/v2c/v3, RMON, Syslog, Dual Image & Config |
| Layer 2+ Features | Static Routing (IPv4/IPv6), OAM, DDM, sFlow 802.1Q VLAN, QinQ, Private VLAN STP/RSTP/MSTP, Loopback Detection |
| Security & Authentication | 802.1X (Port-Based & MAC-Based), Radius, TACACS+ DHCP Snooping, ARP Inspection, DoS Defense IP-MAC-Port Binding, Port Security |
| Quality of Service (QoS) | 8 Priority Queues, 802.1p, DSCP, Rate Limiting Scheduling: SP, WRR, SP+WRR |
| Multicast Support | IGMP Snooping v1/v2/v3 MLD Snooping v1/v2 IGMP Authentication, Multicast VLAN (MVR) |
| IPv6 Support | Dual Stack IPv4/IPv6 IPv6 ACL, IPv6 Static Routing MLD Snooping, IPv6 Neighbor Discovery |
| Link Aggregation | Supports LACP & Static LAG Up to 26 Aggregation Groups, 8 Ports per Group |
| Enclosure | 1U 19-inch Rack-Mountable Steel Case |
| Cooling | 3 × Active Cooling Fans |
| Power Supply | AC 100–240 V ~ 50/60 Hz |
| Power Consumption | Max: 635.7 W (with PoE load) Typical: 49.19 W (without PoE) |
| Dimensions | 440 × 330 × 44 mm (17.3 × 13.0 × 1.7 in) |
| Operating Environment | Temperature: 0–40°C (Operating), -40–70°C (Storage) Humidity: 10–90% RH (non-condensing) |
| Certifications | CE, FCC, RoHS |
| Package Contents | SG3452XP Switch, Power Cord, Rack Mount Kit, Rubber Feet, Quick Installation Guide |
SG3452XP - Omada 48-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch with 48-Port PoE+
- Regular price
- $1,399.00
- Sale price
- $1,399.00
