The ER8411 is a business‑grade VPN/security gateway router in TP‑Link’s Omada line, designed for high throughput and multi‑WAN deployment. It offers two 10 G SFP+ ports (one for WAN, one for WAN/LAN) plus multiple 1 G ports, making it suitable for networks needing 10 Gbps backbone connectivity. It integrates tightly with the Omada SDN platform, allowing centralized cloud or local management, zero‑touch provisioning, monitoring, and policy enforcement. It supports multiple VPN types (IPSec, SSL, PPTP, L2TP, OpenVPN), advanced routing, load balancing, firewall, and security features for enterprise branch networks.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| CPU / Memory / Storage | Quad‑core 2.2 GHz CPU; 4 GB DDR4 DRAM; 4 MB SPI NOR + 256 MB NAND Flash |
| Ports & Interfaces | • 2 × 10G SFP+ ports (1 WAN, 1 WAN/LAN) • 1 × 1G SFP (WAN/LAN) • 8 × 1G RJ‑45 (WAN/LAN) • 1 × RJ‑45 console • 2 × USB 3.0 (for 3G/4G modem as WAN backup) |
| Standards / Protocols / Networking | IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1q; TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP/HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
| Network Media / Cable Types | 10BASE‑T (UTP Cat3/4/5), 100BASE‑TX (Cat5/5e), 1000BASE‑T (Cat5e/Cat6), up to 100 m per link |
| Power / Fans / Enclosure | Redundant dual power supplies (100–240 VAC, 50/60 Hz); 2 fans; steel enclosure; rack mountable; 4 kV surge protection |
| Dimensions / Environmental | 440 × 220 × 44 mm (17.3″ × 8.7″ × 1.7″); Operating temp: 0–40 °C; Storage temp: –40 to 70 °C; Humidity: 10–90% RH non‑condensing (operating) |
| Max Power Consumption | ~ 26.36 W (with USB 3.0 connected); ~ 19.12 W (without USB 3.0) |
| IPS / DPI Throughput | IPS: TCP 4,924 Mbps / UDP 4,521 Mbps; DPI: TCP 5,524 Mbps / UDP 3,547 Mbps |
| VPN / Encryption Throughput | WireGuard: 1,411 Mbps; IPsec SHA1‑AES256: 2,140 Mbps; IPsec SHA2‑AES256: 2,080 Mbps; OpenVPN: 1,665 Mbps |
| NAT / Packet Forwarding | NAT (Static IP): ~9,445 Mbps upload / ~9,449 Mbps download NAT (DHCP): ~9,427 / ~9,426 Mbps NAT (PPPoE): ~9,414 / ~9,102 Mbps NAT (L2TP): ~4,231 / ~4,170 Mbps NAT (PPTP): ~3,934 / ~3,822 Mbps 64‑byte packet rate: ~1,080 / ~1,030 Mbps 1,518‑byte packets: ~9,970 Mbps Concurrent sessions: up to 2,300,000 New sessions per second: 20,000 |
| WAN / Routing / Load Balancing | Supports static/dynamic IP, PPPoE, PPTP, L2TP, 6to4, pass‑through; multi‑WAN load balancing, link backup, policy routing, online detection |
| VLAN / NAT / Security | 802.1Q VLAN, IGMP v2/v3 proxy, one‑to‑one NAT, multi‑net NAT, DMZ, port triggering, ALG for FTP/H.323/SIP/IPSec/PPTP, SPI Firewall, DoS defense, access control, IP/MAC binding, URL / Web filtering, ARP inspection |
| VPN Features | Supports up to 300 IPSec tunnels, 500 SSL VPN tunnels; LAN‑to‑LAN, client‑to‑LAN; PPTP server & client, L2TP server & client; IKE v1/v2, NAT‑Traversal, Dead Peer Detection, PFS, MD5/SHA1/SHA2, DES/3DES/AES |
| Management / Monitoring | Omada SDN support: Zero‑Touch Provisioning, cloud & local controller, device discovery, unified config, intelligent monitoring, alerts, captive portal, reboot scheduling, syslog, SNMP v1/v2c/v3 |
| Certifications / Package / Others | CE, FCC, RoHS; includes ER8411 unit, power cord, rack‑mount kit, quick installation guide; comes with environment/humidity tolerances as above |
Learn what makes this product unique and why it’s right for you.
The ER8411 is a business‑grade VPN/security gateway router in TP‑Link’s Omada line, designed for high throughput and multi‑WAN deployment. It offers two 10 G SFP+ ports (one for WAN, one for WAN/LAN) plus multiple 1 G ports, making it suitable for networks needing 10 Gbps backbone connectivity. It integrates tightly with the Omada SDN platform, allowing centralized cloud or local management, zero‑touch provisioning, monitoring, and policy enforcement. It supports multiple VPN types (IPSec, SSL, PPTP, L2TP, OpenVPN), advanced routing, load balancing, firewall, and security features for enterprise branch networks.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| CPU / Memory / Storage | Quad‑core 2.2 GHz CPU; 4 GB DDR4 DRAM; 4 MB SPI NOR + 256 MB NAND Flash |
| Ports & Interfaces | • 2 × 10G SFP+ ports (1 WAN, 1 WAN/LAN) • 1 × 1G SFP (WAN/LAN) • 8 × 1G RJ‑45 (WAN/LAN) • 1 × RJ‑45 console • 2 × USB 3.0 (for 3G/4G modem as WAN backup) |
| Standards / Protocols / Networking | IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1q; TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP/HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
| Network Media / Cable Types | 10BASE‑T (UTP Cat3/4/5), 100BASE‑TX (Cat5/5e), 1000BASE‑T (Cat5e/Cat6), up to 100 m per link |
| Power / Fans / Enclosure | Redundant dual power supplies (100–240 VAC, 50/60 Hz); 2 fans; steel enclosure; rack mountable; 4 kV surge protection |
| Dimensions / Environmental | 440 × 220 × 44 mm (17.3″ × 8.7″ × 1.7″); Operating temp: 0–40 °C; Storage temp: –40 to 70 °C; Humidity: 10–90% RH non‑condensing (operating) |
| Max Power Consumption | ~ 26.36 W (with USB 3.0 connected); ~ 19.12 W (without USB 3.0) |
| IPS / DPI Throughput | IPS: TCP 4,924 Mbps / UDP 4,521 Mbps; DPI: TCP 5,524 Mbps / UDP 3,547 Mbps |
| VPN / Encryption Throughput | WireGuard: 1,411 Mbps; IPsec SHA1‑AES256: 2,140 Mbps; IPsec SHA2‑AES256: 2,080 Mbps; OpenVPN: 1,665 Mbps |
| NAT / Packet Forwarding | NAT (Static IP): ~9,445 Mbps upload / ~9,449 Mbps download NAT (DHCP): ~9,427 / ~9,426 Mbps NAT (PPPoE): ~9,414 / ~9,102 Mbps NAT (L2TP): ~4,231 / ~4,170 Mbps NAT (PPTP): ~3,934 / ~3,822 Mbps 64‑byte packet rate: ~1,080 / ~1,030 Mbps 1,518‑byte packets: ~9,970 Mbps Concurrent sessions: up to 2,300,000 New sessions per second: 20,000 |
| WAN / Routing / Load Balancing | Supports static/dynamic IP, PPPoE, PPTP, L2TP, 6to4, pass‑through; multi‑WAN load balancing, link backup, policy routing, online detection |
| VLAN / NAT / Security | 802.1Q VLAN, IGMP v2/v3 proxy, one‑to‑one NAT, multi‑net NAT, DMZ, port triggering, ALG for FTP/H.323/SIP/IPSec/PPTP, SPI Firewall, DoS defense, access control, IP/MAC binding, URL / Web filtering, ARP inspection |
| VPN Features | Supports up to 300 IPSec tunnels, 500 SSL VPN tunnels; LAN‑to‑LAN, client‑to‑LAN; PPTP server & client, L2TP server & client; IKE v1/v2, NAT‑Traversal, Dead Peer Detection, PFS, MD5/SHA1/SHA2, DES/3DES/AES |
| Management / Monitoring | Omada SDN support: Zero‑Touch Provisioning, cloud & local controller, device discovery, unified config, intelligent monitoring, alerts, captive portal, reboot scheduling, syslog, SNMP v1/v2c/v3 |
| Certifications / Package / Others | CE, FCC, RoHS; includes ER8411 unit, power cord, rack‑mount kit, quick installation guide; comes with environment/humidity tolerances as above |
ER8411 - Omada VPN Router with 10G Ports
- Regular price
- $879.00
- Sale price
- $879.00
- Regular price
-
Couldn't load pickup availability
