The TP-Link ER7406 is a versatile gigabit VPN gateway ideal for small and medium businesses. It features multiple WAN ports (including USB support for LTE failover), advanced VPN protocols (including IPSec, GRE, OpenVPN, WireGuard, and SSL), deep packet inspection (DPI), and comprehensive security features such as IDS/IPS, DoS defense, and application filtering. With support for the Omada SDN platform, it provides centralized cloud management, making it a flexible and secure choice for modern networks.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model | TP-Link ER7406 |
| Form Factor | Rackmount/Desktop |
| Ports | 1 × Gigabit SFP WAN/LAN port 1 × Gigabit RJ45 WAN port 4 × Gigabit RJ45 WAN/LAN ports 1 × USB 3.0 port (for 4G LTE dongle or storage) |
| WAN Capability | Supports up to 5 WAN ports (with load balancing and failover) |
| VPN Protocols | IPSec, PPTP, L2TP, OpenVPN, GRE, WireGuard, SSL VPN |
| VPN Capacity | IPSec VPN: 100 tunnels SSL VPN: 50 tunnels |
| Firewall & Security | Stateful firewall URL filtering IP/MAC/Port binding Access Control Lists (ACL) DoS/DDoS protection DPI (Deep Packet Inspection) IDS/IPS (Intrusion Detection/Prevention System) |
| Routing Features | Static Routing, Policy Routing, NAT, VLAN, One-to-One NAT, Port Forwarding, Load Balancing |
| Performance | NAT Throughput: ~945 Mbps IPSec VPN Throughput: ~617 Mbps WireGuard VPN: ~341 Mbps OpenVPN: ~139 Mbps SSL VPN: ~131 Mbps DPI Throughput: ~933 Mbps Concurrent Sessions: 150,000 New Sessions per Second: ~5,300 |
| Memory | 512 MB DDR4 RAM, 128 MB NAND Flash |
| Management | Omada SDN (Cloud/Controller/Standalone) Web UI, CLI (Console), SNMP, SSH, Syslog |
| Dimensions | 294 × 140 × 44 mm (11.6 × 5.5 × 1.7 in) |
| Power | 100–240V AC, 50/60Hz |
| Power Consumption | Max 7.5W (with USB in use) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Certifications | CE, FCC, RoHS |
The TP-Link ER7406 is a versatile gigabit VPN gateway ideal for small and medium businesses. It features multiple WAN ports (including USB support for LTE failover), advanced VPN protocols (including IPSec, GRE, OpenVPN, WireGuard, and SSL), deep packet inspection (DPI), and comprehensive security features such as IDS/IPS, DoS defense, and application filtering. With support for the Omada SDN platform, it provides centralized cloud management, making it a flexible and secure choice for modern networks.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model | TP-Link ER7406 |
| Form Factor | Rackmount/Desktop |
| Ports | 1 × Gigabit SFP WAN/LAN port 1 × Gigabit RJ45 WAN port 4 × Gigabit RJ45 WAN/LAN ports 1 × USB 3.0 port (for 4G LTE dongle or storage) |
| WAN Capability | Supports up to 5 WAN ports (with load balancing and failover) |
| VPN Protocols | IPSec, PPTP, L2TP, OpenVPN, GRE, WireGuard, SSL VPN |
| VPN Capacity | IPSec VPN: 100 tunnels SSL VPN: 50 tunnels |
| Firewall & Security | Stateful firewall URL filtering IP/MAC/Port binding Access Control Lists (ACL) DoS/DDoS protection DPI (Deep Packet Inspection) IDS/IPS (Intrusion Detection/Prevention System) |
| Routing Features | Static Routing, Policy Routing, NAT, VLAN, One-to-One NAT, Port Forwarding, Load Balancing |
| Performance | NAT Throughput: ~945 Mbps IPSec VPN Throughput: ~617 Mbps WireGuard VPN: ~341 Mbps OpenVPN: ~139 Mbps SSL VPN: ~131 Mbps DPI Throughput: ~933 Mbps Concurrent Sessions: 150,000 New Sessions per Second: ~5,300 |
| Memory | 512 MB DDR4 RAM, 128 MB NAND Flash |
| Management | Omada SDN (Cloud/Controller/Standalone) Web UI, CLI (Console), SNMP, SSH, Syslog |
| Dimensions | 294 × 140 × 44 mm (11.6 × 5.5 × 1.7 in) |
| Power | 100–240V AC, 50/60Hz |
| Power Consumption | Max 7.5W (with USB in use) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Certifications | CE, FCC, RoHS |
ER7406 - Omada Gigabit Rackmount/Desktop VPN Gateway
