About
The ER7212PC is a compact all‑in‑one device combining three network functions: a gigabit VPN router, an 8‑port PoE+ switch, and an embedded Omada SDN controller. It is designed for small offices or advanced home networks, consolidating multiple devices into one. With multiple WAN ports, robust VPN support, and a 110 W PoE budget, it simplifies deployment while supporting centralized management of access points and switches.
TECHNICAL SPECIFICATION
Category | Details |
---|---|
Model / Series | ER7212PC, Omada 3‑in‑1 Gigabit VPN Gateway |
3‑in‑1 Integration | Router + PoE+ switch + Omada SDN controller |
WAN / Uplink Ports | 2 × Gigabit SFP (WAN/LAN) + 1 × Gigabit RJ45 WAN + 1 × Gigabit RJ45 (LAN/WAN) |
LAN / PoE Ports | 8 × Gigabit RJ45 LAN ports with PoE+ support (802.3at/af), total PoE budget: 110 W |
Processor / Memory / Storage | Dual‑core CPU, 1 GB DDR3, Flash: 8 Mb NOR + 4 GB eMMC |
Physical / Enclosure / Mounting | Steel enclosure, fanless, desktop or wall mount, surge protection 4 kV |
Dimensions | 226 × 131 × 35 mm (8.9 × 5.2 × 1.4 in) |
Power & Consumption | Adapter: 53.5 V DC / 2.43 A; Max consumption: ~133.2 W (with full PoE), ~13.88 W (without PoE) |
Operating Environment | 0 °C to 45 °C; Storage: –40 °C to 70 °C; Humidity: 10%–90% non‑condensing |
Network & Protocol Support | IEEE 802.3/802.3u/802.3ab, 802.1q VLAN; TCP/IP, DHCP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, SNMP |
WAN Features / Routing | Multi‑WAN load balancing and failover, policy routing, static routing, NAT (multi‑net, DMZ, port forwarding), VPN passthrough, ALG support |
VPN / Tunneling | IPSec (up to 20 tunnels), OpenVPN, L2TP, PPTP; supports LAN‑to‑LAN and client‑to‑LAN modes |
Performance / Throughput | Static NAT: ~942.1 / 935.5 Mbps VPN (IPSec AES256): ~168.5 Mbps OpenVPN: ~34 Mbps L2TP (encrypted): ~333.2 Mbps PPTP (encrypted): ~401.4 Mbps Concurrent Sessions: ~24,980 New Sessions/sec: ~1,900 |
Security / Firewall / Filtering | Stateful firewall, DoS / DDoS protection (flood defense, scan blocking, block WAN ping), IP/MAC binding, URL filtering, ACLs |
Controller / Management | Built‑in Omada SDN controller (manages up to 10 EAPs, 2 switches), web UI, Omada Cloud access, remote management, software updates |
LED / Indicators / Buttons | Power, System, Cloud, PoE Max, SFP1, SFP2, WAN (speed/link/activity), LAN (speed/link/activity); Reset button |
Certifications / Compliance | CE, FCC, RoHS |
The ER7212PC is a compact all‑in‑one device combining three network functions: a gigabit VPN router, an 8‑port PoE+ switch, and an embedded Omada SDN controller. It is designed for small offices or advanced home networks, consolidating multiple devices into one. With multiple WAN ports, robust VPN support, and a 110 W PoE budget, it simplifies deployment while supporting centralized management of access points and switches.
TECHNICAL SPECIFICATION
Category | Details |
---|---|
Model / Series | ER7212PC, Omada 3‑in‑1 Gigabit VPN Gateway |
3‑in‑1 Integration | Router + PoE+ switch + Omada SDN controller |
WAN / Uplink Ports | 2 × Gigabit SFP (WAN/LAN) + 1 × Gigabit RJ45 WAN + 1 × Gigabit RJ45 (LAN/WAN) |
LAN / PoE Ports | 8 × Gigabit RJ45 LAN ports with PoE+ support (802.3at/af), total PoE budget: 110 W |
Processor / Memory / Storage | Dual‑core CPU, 1 GB DDR3, Flash: 8 Mb NOR + 4 GB eMMC |
Physical / Enclosure / Mounting | Steel enclosure, fanless, desktop or wall mount, surge protection 4 kV |
Dimensions | 226 × 131 × 35 mm (8.9 × 5.2 × 1.4 in) |
Power & Consumption | Adapter: 53.5 V DC / 2.43 A; Max consumption: ~133.2 W (with full PoE), ~13.88 W (without PoE) |
Operating Environment | 0 °C to 45 °C; Storage: –40 °C to 70 °C; Humidity: 10%–90% non‑condensing |
Network & Protocol Support | IEEE 802.3/802.3u/802.3ab, 802.1q VLAN; TCP/IP, DHCP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, SNMP |
WAN Features / Routing | Multi‑WAN load balancing and failover, policy routing, static routing, NAT (multi‑net, DMZ, port forwarding), VPN passthrough, ALG support |
VPN / Tunneling | IPSec (up to 20 tunnels), OpenVPN, L2TP, PPTP; supports LAN‑to‑LAN and client‑to‑LAN modes |
Performance / Throughput | Static NAT: ~942.1 / 935.5 Mbps VPN (IPSec AES256): ~168.5 Mbps OpenVPN: ~34 Mbps L2TP (encrypted): ~333.2 Mbps PPTP (encrypted): ~401.4 Mbps Concurrent Sessions: ~24,980 New Sessions/sec: ~1,900 |
Security / Firewall / Filtering | Stateful firewall, DoS / DDoS protection (flood defense, scan blocking, block WAN ping), IP/MAC binding, URL filtering, ACLs |
Controller / Management | Built‑in Omada SDN controller (manages up to 10 EAPs, 2 switches), web UI, Omada Cloud access, remote management, software updates |
LED / Indicators / Buttons | Power, System, Cloud, PoE Max, SFP1, SFP2, WAN (speed/link/activity), LAN (speed/link/activity); Reset button |
Certifications / Compliance | CE, FCC, RoHS |
ER7212PC - Omada 3-in-1 Gigabit VPN Gateway
- Regular price
- $299.00
- Sale price
- $299.00
