About
Learn what makes this product unique and why it’s right for you.
The ER707‑M2 is a powerful multi‑gigabit VPN gateway designed for networking environments requiring higher throughput. It offers dual 2.5 GbE ports, multiple WAN interfaces, and robust VPN support (including SSL, IPSec, GRE, WireGuard, OpenVPN), along with integrated firewall, DPI, and intrusion prevention. It works natively with the Omada SDN system for centralized management, zero‑touch provisioning, and network orchestration across sites.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Ports / Interfaces | 1 × 2.5 Gbps RJ45 (WAN) 1 × 2.5 Gbps RJ45 (WAN/LAN) 1 × Gigabit SFP (WAN/LAN) 4 × Gigabit RJ45 (WAN/LAN) 1 × USB 2.0 (for storage or LTE dongle backup) |
| Hardware / Memory / Storage | 1 GB DDR4 RAM 128 MB NAND flash |
| Form Factor & Build | Fanless, steel enclosure Desktop / Wall mountable Surge protection: 4 kV |
| Dimensions | 226 × 131 × 35 mm (8.9 × 5.2 × 1.4 in) |
| Power & Consumption | Power Input: 12V ⎓ 1.5A adapter Consumption: ~14.2 W (with USB connected), ~7.1 W (without USB) |
| Performance & Throughput | NAT (Static IP): ~2,365 / 2,364 Mbps NAT (DHCP): ~2,364 / 2,366 Mbps NAT (PPPoE): ~2,347 / 2,348 Mbps IPSec VPN (AES256 etc): ~650–750 Mbps (depending on algorithm) WireGuard: ~343 Mbps SSL VPN: ~142.99 Mbps DPI / Firewall / IDS/IPS: high throughput for application inspection Concurrent Sessions: 500,000 New Sessions per Second: 6,000 |
| WAN & Routing Features | Supports up to 6 WAN links (RJ45, SFP, USB) with load balancing and failover IPv4 / IPv6 support, PPPoE, Static IP, Dynamic IP, L2TP, PPTP Policy routing, intelligent routing, static routing VLAN (802.1Q), multi‑net NAT, port forwarding, DMZ, ALG, NAT traversal Multi‑net DHCP, DHCPv6 (in standalone mode) |
| VPN / Tunneling | IPSec (up to 100 tunnels) SSL VPN (up to 60 tunnels) GRE, PPTP, L2TP, OpenVPN, WireGuard Supports LAN‑to‑LAN and Client‑to‑LAN modes IKEv1/v2, NAT traversal, Perfect Forward Secrecy, DPD, etc. |
| Security / Firewall / Filtering | Stateful firewall, DoS / DDoS protection IP/MAC binding, ARP inspection, ARP scanning URL filtering, Web group filtering, ACLs Signature‑based IDS/IPS with updates Application control, DPI |
| Basic / Network Functions | DHCP server/client, address reservation MAC cloning IPv6 (Static, DHCPv6, SLAAC, pass‑through) UPnP, IGMP v2/v3, QoS, traffic prioritization Session limiting, bandwidth control (guarantee, limit) |
| Management & Controller | Omada SDN support (cloud / on‑prem / local) Zero-Touch Provisioning (ZTP) Web UI, CLI, SNMP, SSH, remote management Firmware upgrade, logging, monitoring |
| LEDs / Buttons / Indicators | Power, System, SFP, USB, WAN (speed/link/activity), LAN (speed/link/activity) Reset button |
| Operating Conditions | Operating Temperature: 0 °C to 40 °C Storage Temperature: –40 °C to 70 °C Humidity: 10% to 90% non‑condensing |
| Certifications / Compliance | CE, FCC, RoHS |
Learn what makes this product unique and why it’s right for you.
The ER707‑M2 is a powerful multi‑gigabit VPN gateway designed for networking environments requiring higher throughput. It offers dual 2.5 GbE ports, multiple WAN interfaces, and robust VPN support (including SSL, IPSec, GRE, WireGuard, OpenVPN), along with integrated firewall, DPI, and intrusion prevention. It works natively with the Omada SDN system for centralized management, zero‑touch provisioning, and network orchestration across sites.
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Ports / Interfaces | 1 × 2.5 Gbps RJ45 (WAN) 1 × 2.5 Gbps RJ45 (WAN/LAN) 1 × Gigabit SFP (WAN/LAN) 4 × Gigabit RJ45 (WAN/LAN) 1 × USB 2.0 (for storage or LTE dongle backup) |
| Hardware / Memory / Storage | 1 GB DDR4 RAM 128 MB NAND flash |
| Form Factor & Build | Fanless, steel enclosure Desktop / Wall mountable Surge protection: 4 kV |
| Dimensions | 226 × 131 × 35 mm (8.9 × 5.2 × 1.4 in) |
| Power & Consumption | Power Input: 12V ⎓ 1.5A adapter Consumption: ~14.2 W (with USB connected), ~7.1 W (without USB) |
| Performance & Throughput | NAT (Static IP): ~2,365 / 2,364 Mbps NAT (DHCP): ~2,364 / 2,366 Mbps NAT (PPPoE): ~2,347 / 2,348 Mbps IPSec VPN (AES256 etc): ~650–750 Mbps (depending on algorithm) WireGuard: ~343 Mbps SSL VPN: ~142.99 Mbps DPI / Firewall / IDS/IPS: high throughput for application inspection Concurrent Sessions: 500,000 New Sessions per Second: 6,000 |
| WAN & Routing Features | Supports up to 6 WAN links (RJ45, SFP, USB) with load balancing and failover IPv4 / IPv6 support, PPPoE, Static IP, Dynamic IP, L2TP, PPTP Policy routing, intelligent routing, static routing VLAN (802.1Q), multi‑net NAT, port forwarding, DMZ, ALG, NAT traversal Multi‑net DHCP, DHCPv6 (in standalone mode) |
| VPN / Tunneling | IPSec (up to 100 tunnels) SSL VPN (up to 60 tunnels) GRE, PPTP, L2TP, OpenVPN, WireGuard Supports LAN‑to‑LAN and Client‑to‑LAN modes IKEv1/v2, NAT traversal, Perfect Forward Secrecy, DPD, etc. |
| Security / Firewall / Filtering | Stateful firewall, DoS / DDoS protection IP/MAC binding, ARP inspection, ARP scanning URL filtering, Web group filtering, ACLs Signature‑based IDS/IPS with updates Application control, DPI |
| Basic / Network Functions | DHCP server/client, address reservation MAC cloning IPv6 (Static, DHCPv6, SLAAC, pass‑through) UPnP, IGMP v2/v3, QoS, traffic prioritization Session limiting, bandwidth control (guarantee, limit) |
| Management & Controller | Omada SDN support (cloud / on‑prem / local) Zero-Touch Provisioning (ZTP) Web UI, CLI, SNMP, SSH, remote management Firmware upgrade, logging, monitoring |
| LEDs / Buttons / Indicators | Power, System, SFP, USB, WAN (speed/link/activity), LAN (speed/link/activity) Reset button |
| Operating Conditions | Operating Temperature: 0 °C to 40 °C Storage Temperature: –40 °C to 70 °C Humidity: 10% to 90% non‑condensing |
| Certifications / Compliance | CE, FCC, RoHS |
ER707-M2 - Omada Multi-Gigabit VPN Gateway
- Regular price
- $249.00
- Sale price
- $249.00
- Regular price
-
Couldn't load pickup availability
