About
The EdgeRouter 4 (ER‑4) from Ubiquiti is a high‑performance router in the EdgeMAX series. It features a quad‑core 1 GHz MIPS64 CPU, 1 GB of DDR3 RAM, and multiple ports including 3 Gigabit RJ‑45 ports and 1 SFP port for fiber connectivity. It is designed for advanced routing, firewall, VPN, and network segmentation tasks, and is capable of processing up to ~3.4 million packets per second and achieving a line rate of 4 Gbps for appropriately sized packets.
It runs Ubiquiti’s EdgeOS, offering a web UI, CLI, and support for routing protocols (OSPF, BGP, RIP), firewall rules, NAT, QoS, VLANs, VPN, IPv6, and centralized management via UNMS (or Ubiquiti’s network management tools).
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model / Series | EdgeRouter 4 (ER‑4) |
| Processor | 4‑core 1 GHz MIPS64 |
| System Memory (RAM) | 1 GB DDR3 |
| Flash / Storage | 4 GB eMMC + 8 MB SPI NOR |
| Interfaces / Ports | (3) 10/100/1000 RJ‑45 routing ports + (1) 1 Gbps SFP port + (1) RJ‑45 serial console |
| Performance / Forwarding | ≈ 3,400,000 packets/sec (64‑byte) ; up to 4 Gbps (≥128‑byte) |
| Power / Consumption | Internal AC power adapter, 100‑240 VAC, 50/60 Hz; maximum ~13 W |
| LEDs / Indicators | Speed / Link / Activity (on data ports), Link / Activity (on SFP) |
| Reset / Button | Factory reset button |
| Physical / Mechanical | Dimensions: 229 × 136.5 × 31.1 mm ; Weight: 795 g |
| Operating Conditions | Temperature: –10 °C to 50 °C ; Humidity: 10% to 90% non‑condensing |
| Certifications | CE, FCC, IC |
| Mounting / Form Factor | Wall mountable; rack‑mountable with optional kit (ER‑RMKIT) |
| Routing / Protocols / Features | Static & dynamic routing (OSPF, BGP, RIP), VLAN (802.1Q), NAT, firewall / ACLs, VPN (IPsec, etc.), QoS, IPv6, DHCP server/relay, SNMP, DPI, VRRP, bonding support |
The EdgeRouter 4 (ER‑4) from Ubiquiti is a high‑performance router in the EdgeMAX series. It features a quad‑core 1 GHz MIPS64 CPU, 1 GB of DDR3 RAM, and multiple ports including 3 Gigabit RJ‑45 ports and 1 SFP port for fiber connectivity. It is designed for advanced routing, firewall, VPN, and network segmentation tasks, and is capable of processing up to ~3.4 million packets per second and achieving a line rate of 4 Gbps for appropriately sized packets.
It runs Ubiquiti’s EdgeOS, offering a web UI, CLI, and support for routing protocols (OSPF, BGP, RIP), firewall rules, NAT, QoS, VLANs, VPN, IPv6, and centralized management via UNMS (or Ubiquiti’s network management tools).
TECHNICAL SPECIFICATION
| Category | Details |
|---|---|
| Model / Series | EdgeRouter 4 (ER‑4) |
| Processor | 4‑core 1 GHz MIPS64 |
| System Memory (RAM) | 1 GB DDR3 |
| Flash / Storage | 4 GB eMMC + 8 MB SPI NOR |
| Interfaces / Ports | (3) 10/100/1000 RJ‑45 routing ports + (1) 1 Gbps SFP port + (1) RJ‑45 serial console |
| Performance / Forwarding | ≈ 3,400,000 packets/sec (64‑byte) ; up to 4 Gbps (≥128‑byte) |
| Power / Consumption | Internal AC power adapter, 100‑240 VAC, 50/60 Hz; maximum ~13 W |
| LEDs / Indicators | Speed / Link / Activity (on data ports), Link / Activity (on SFP) |
| Reset / Button | Factory reset button |
| Physical / Mechanical | Dimensions: 229 × 136.5 × 31.1 mm ; Weight: 795 g |
| Operating Conditions | Temperature: –10 °C to 50 °C ; Humidity: 10% to 90% non‑condensing |
| Certifications | CE, FCC, IC |
| Mounting / Form Factor | Wall mountable; rack‑mountable with optional kit (ER‑RMKIT) |
| Routing / Protocols / Features | Static & dynamic routing (OSPF, BGP, RIP), VLAN (802.1Q), NAT, firewall / ACLs, VPN (IPsec, etc.), QoS, IPv6, DHCP server/relay, SNMP, DPI, VRRP, bonding support |
ER‑4 - EdgeRouter 4
- Regular price
- $349.50
- Sale price
- $349.50
- Regular price
-
$411.13
Couldn't load pickup availability
