About
The EAP772‑Outdoor is a robust, weatherproof Omada Tri‑Band Omnidirectional Wi‑Fi 7 access point ideal for demanding outdoor environments. Boasting an IP68 rating, it remains fully protected against dust and can endure submersion up to 1.5 meters—far beyond standard outdoor requirements. It delivers exceptional tri‑band performance with aggregate speeds up to 9.3 Gbps, supports AFC-cleared 6 GHz operation, and offers seamless mesh integration and roaming via Omada SDN for reliable, unified network management
SPECIFICATION
| Feature | Description |
|---|---|
| Wi‑Fi Standard & Bands | Wi‑Fi 7 (802.11be), Tri‑Band omnidirectional (2.4 GHz, 5 GHz, 6 GHz with AFC) |
| Maximum Speeds (Aggregate) | 6 GHz: ~5,765 Mbps 5 GHz: ~2,882 Mbps 2.4 GHz: ~688 Mbps **Total ≈ 9.3 Gbps** |
| Coverage | Up to 300 m² (approx. 3,200 ft²) omnidirectional coverage |
| Ethernet Interface | 1 × 2.5 GbE RJ45 (802.3at PoE+) |
| Weatherproof Rating | IP68 (dust-tight, water submersion up to 1.5 m for 30–60 mins) |
| Mounting Options | Wall or pole (mounting kits included) |
| Antenna & GNSS | 2.4 GHz: 2× 4 dBi dual‑polarized 5 GHz: 2× 6 dBi 6 GHz: 2× 6 dBi Integrated GNSS receiver (GPS, Galileo, GLONASS, BeiDou) |
| Concurrent Clients | 380+ devices |
| Key Wireless Features | 4K‑QAM, OFDMA, MU‑MIMO, MLO, 320 MHz channels, Mesh, Seamless Roaming (802.11k/v/r), Band Steering, Load Balancing, Airtime Fairness, Beamforming, QoS, Schedule, Rate Limit |
| Security Features | Captive Portal, Access Control, MAC Filtering, VLAN, Rogue AP Detection, Wireless Isolation, WPA2/3, OWE, 802.1X |
| Management Options | Omada SDN (Cloud/Controller), Omada App, SNMP v1/v2c, SSH, Web UI, Email alerts, Syslog, Multi-site, Zero-Touch Provisioning |
| Power Consumption | Approx. 21.5 W (PoE) |
| Dimensions | 230 × 207.5 × 69.7 mm (9.1 × 8.2 × 2.8 in) |
| Operating Temperature | −30 °C to 70 °C (−22 °F to 158 °F) |
| Certifications | CE, FCC, RoHS |
The EAP772‑Outdoor is a robust, weatherproof Omada Tri‑Band Omnidirectional Wi‑Fi 7 access point ideal for demanding outdoor environments. Boasting an IP68 rating, it remains fully protected against dust and can endure submersion up to 1.5 meters—far beyond standard outdoor requirements. It delivers exceptional tri‑band performance with aggregate speeds up to 9.3 Gbps, supports AFC-cleared 6 GHz operation, and offers seamless mesh integration and roaming via Omada SDN for reliable, unified network management
SPECIFICATION
| Feature | Description |
|---|---|
| Wi‑Fi Standard & Bands | Wi‑Fi 7 (802.11be), Tri‑Band omnidirectional (2.4 GHz, 5 GHz, 6 GHz with AFC) |
| Maximum Speeds (Aggregate) | 6 GHz: ~5,765 Mbps 5 GHz: ~2,882 Mbps 2.4 GHz: ~688 Mbps **Total ≈ 9.3 Gbps** |
| Coverage | Up to 300 m² (approx. 3,200 ft²) omnidirectional coverage |
| Ethernet Interface | 1 × 2.5 GbE RJ45 (802.3at PoE+) |
| Weatherproof Rating | IP68 (dust-tight, water submersion up to 1.5 m for 30–60 mins) |
| Mounting Options | Wall or pole (mounting kits included) |
| Antenna & GNSS | 2.4 GHz: 2× 4 dBi dual‑polarized 5 GHz: 2× 6 dBi 6 GHz: 2× 6 dBi Integrated GNSS receiver (GPS, Galileo, GLONASS, BeiDou) |
| Concurrent Clients | 380+ devices |
| Key Wireless Features | 4K‑QAM, OFDMA, MU‑MIMO, MLO, 320 MHz channels, Mesh, Seamless Roaming (802.11k/v/r), Band Steering, Load Balancing, Airtime Fairness, Beamforming, QoS, Schedule, Rate Limit |
| Security Features | Captive Portal, Access Control, MAC Filtering, VLAN, Rogue AP Detection, Wireless Isolation, WPA2/3, OWE, 802.1X |
| Management Options | Omada SDN (Cloud/Controller), Omada App, SNMP v1/v2c, SSH, Web UI, Email alerts, Syslog, Multi-site, Zero-Touch Provisioning |
| Power Consumption | Approx. 21.5 W (PoE) |
| Dimensions | 230 × 207.5 × 69.7 mm (9.1 × 8.2 × 2.8 in) |
| Operating Temperature | −30 °C to 70 °C (−22 °F to 158 °F) |
| Certifications | CE, FCC, RoHS |
EAP772 - Outdoor Omada Tri-Band Omnidirectional BE9300 Indoor/Outdoor WiFi 7 Access Point
