About
The EAP770 (BE11000) is a slim, high-performance Wi‑Fi 7 (802.11be) ceiling-mount access point engineered for modern business environments. Featuring tri-band support (2.4 GHz / 5 GHz / 6 GHz — with clean 6 GHz spectrum), it delivers combined speeds of up to ≈ 11 Gbps. Equipped with a 10 GbE (PoE++) port, it supports Multi-Link Operation (MLO), 320 MHz bandwidth, and 4096-QAM for ultra-low latency and high throughput. Designed for flexible deployments and centralized control, it integrates with TP‑Link's Omada SDN platform, offering mesh, seamless roaming, and optimized auto channel/power adjustments.
SPECIFICATION
| Feature | Description |
|---|---|
| Wi‑Fi Standard | Wi‑Fi 7 (802.11be), Tri‑Band |
| Maximum Speeds | 6 GHz: up to 5,760 Mbps 5 GHz: up to 4,320 Mbps 2.4 GHz: up to 574 Mbps **Total ≈ 11 Gbps** |
| Ethernet Interface | 1 × 10 GbE (802.3bt PoE++ or 12 V/2.5 A DC) |
| Ultra-Thin Design | 220 × 220 × 32.5 mm compact circular arc |
| Antenna Gain | 2.4 GHz: 2 × 3.0 dBi 5 GHz: 2 × 3.0 dBi 6 GHz: 2 × 3.0 dBi |
| Advanced Wireless Features | 4096‑QAM, MLO, HE320, Preamble Puncturing, MU‑MIMO, 320 MHz bandwidth (6 GHz), OFDMA, BSS Coloring, Mesh, Seamless Roaming (802.11k/v/r), Auto Channel / Power Adjustment, Band Steering, Beamforming, Airtime Fairness, Load Balancing, QoS, Wireless & Reboot Scheduling |
| Clients & Coverage | Support for many; typical deployment: ≈ 380+ clients, ~140 m² coverage (US) / ~1500 ft² :contentReference[oaicite:1]{index=1} |
| Management | Omada SDN (Cloud, Hardware, or Software Controller), Omada App, SNMP (v1/v2c/v3), Web UI, Email Alerts, LED Control, Syslog |
| Security | WPA/WPA2/WPA3 Personal & Enterprise, PPSK, VLAN, Captive Portal, MAC Filtering (4,000), Rogue AP Detection, Client Isolation |
| Mounting Options | Ceiling or wall (j-box) with included kits |
| Power Consumption | ≈ 24 W (PoE++), ~21 W (DC) depending on region :contentReference[oaicite:2]{index=2} |
| Operating Conditions | 0–40 °C; 10–90% non‑condensing |
| Certifications | CE, FCC, RoHS, IC |
The EAP770 (BE11000) is a slim, high-performance Wi‑Fi 7 (802.11be) ceiling-mount access point engineered for modern business environments. Featuring tri-band support (2.4 GHz / 5 GHz / 6 GHz — with clean 6 GHz spectrum), it delivers combined speeds of up to ≈ 11 Gbps. Equipped with a 10 GbE (PoE++) port, it supports Multi-Link Operation (MLO), 320 MHz bandwidth, and 4096-QAM for ultra-low latency and high throughput. Designed for flexible deployments and centralized control, it integrates with TP‑Link's Omada SDN platform, offering mesh, seamless roaming, and optimized auto channel/power adjustments.
SPECIFICATION
| Feature | Description |
|---|---|
| Wi‑Fi Standard | Wi‑Fi 7 (802.11be), Tri‑Band |
| Maximum Speeds | 6 GHz: up to 5,760 Mbps 5 GHz: up to 4,320 Mbps 2.4 GHz: up to 574 Mbps **Total ≈ 11 Gbps** |
| Ethernet Interface | 1 × 10 GbE (802.3bt PoE++ or 12 V/2.5 A DC) |
| Ultra-Thin Design | 220 × 220 × 32.5 mm compact circular arc |
| Antenna Gain | 2.4 GHz: 2 × 3.0 dBi 5 GHz: 2 × 3.0 dBi 6 GHz: 2 × 3.0 dBi |
| Advanced Wireless Features | 4096‑QAM, MLO, HE320, Preamble Puncturing, MU‑MIMO, 320 MHz bandwidth (6 GHz), OFDMA, BSS Coloring, Mesh, Seamless Roaming (802.11k/v/r), Auto Channel / Power Adjustment, Band Steering, Beamforming, Airtime Fairness, Load Balancing, QoS, Wireless & Reboot Scheduling |
| Clients & Coverage | Support for many; typical deployment: ≈ 380+ clients, ~140 m² coverage (US) / ~1500 ft² :contentReference[oaicite:1]{index=1} |
| Management | Omada SDN (Cloud, Hardware, or Software Controller), Omada App, SNMP (v1/v2c/v3), Web UI, Email Alerts, LED Control, Syslog |
| Security | WPA/WPA2/WPA3 Personal & Enterprise, PPSK, VLAN, Captive Portal, MAC Filtering (4,000), Rogue AP Detection, Client Isolation |
| Mounting Options | Ceiling or wall (j-box) with included kits |
| Power Consumption | ≈ 24 W (PoE++), ~21 W (DC) depending on region :contentReference[oaicite:2]{index=2} |
| Operating Conditions | 0–40 °C; 10–90% non‑condensing |
| Certifications | CE, FCC, RoHS, IC |
EAP770 - BE11000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
- Regular price
- $369.00
- Sale price
- $369.00
