The TP‑Link EAP683 UR (AX6000) is a sleek, high-performance Wi‑Fi 6 (802.11ax) ceiling-mount access point designed for demanding enterprise and high-density environments. It delivers ultra-fast dual-band throughput—up to 4804 Mbps on 5 GHz and 1148 Mbps on 2.4 GHz—for a combined AX6000-level performance. Armed with 4×4 MU-MIMO, HE160, 1024-QAM, and long OFDM symbols, it ensures efficient, low-latency wireless delivery. A 2.5 GbE PoE+ uplink port consolidates data and power into a single cable, simplifying installations. Integrated into TP-Link’s Omada SDN ecosystem, it supports centralized cloud/controller management, Omada Mesh, seamless roaming, and enterprise-grade security features like WPA3, captive portals, and access control. The design is ultra-thin and mount-ready, making it perfect for offices, campuses, and hospitality venues with coverage up to 185 m² and support for 510+ concurrent clients.





SPECIFICATION

Feature Description
Wi‑Fi Standard Wi‑Fi 6 (802.11ax), Dual‑Band (2.4 GHz & 5 GHz)
Max Wireless Speeds 5 GHz: up to 4804 Mbps
2.4 GHz: up to 1148 Mbps
Total: up to 5952 Mbps (AX6000)
Ethernet Port 1 × 2.5 GbE PoE+ RJ45 (Full-Duplex)
Port Speed 2.5 Gbps
Power Supply 802.3at PoE+ or 12 V / 2 A DC (adapter not included)
Power Consumption EU: ~20.4 W
US: ~23.7 W
Antenna Configuration Internal Omni:
2.4 GHz: 4 × 4 dBi
5 GHz: 4 × 5 dBi
Coverage Area Up to 185 m² (~2,000 ft²)
Concurrent Clients 510+ devices
Wireless Technologies HE160 (160 MHz), 1024‑QAM, OFDMA, MU‑MIMO (4×4 DL/UL), Seamless Roaming (802.11k/v/r), Omada Mesh, Band Steering, Airtime Fairness, Beamforming, Load Balancing, QoS (WMM), Multiple SSIDs (up to 16), Schedule, Rate Limit
Security Features WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, Captive Portal, VLAN, Rogue AP Detection, MAC Filtering, Wireless Isolation
Management Options Omada SDN (Cloud, Software, Hardware Controllers), Omada App, SNMP v1/v2c/3, Web UI (HTTP/HTTPS), SSH, Email Alerts, LED Control, Syslog, Zero-Touch Provisioning
Dimensions 220 × 220 × 32.5 mm
Mounting Ceiling or Wall Mount (kits included)
Operating Conditions 0–40 °C; 10–90% humidity (non‑condensing)
Certifications CE, FCC, RoHS
