About
The EAP673 is a business-grade, ceiling- or wall-mount Wi‑Fi 6 access point designed for environments like offices, hotels, retail, and meeting rooms. It delivers blazing-fast AX5400 dual-band speeds (up to 4804 Mbps on 5 GHz and 574 Mbps on 2.4 GHz), supports 160 MHz channels for peak performance, and integrates seamlessly into the Omada SDN for efficient centralized management. Powered via 802.3at PoE+ or optional DC adapter, it also features Bluetooth 5.2 for added flexibility.
SPECIFICATION
| Feature | Description |
|---|---|
| Wireless Standard | Wi‑Fi 6 (802.11ax), backward compatible with 802.11a/b/g/n/ac |
| Wi‑Fi Speeds | AX5400: 4804 Mbps @ 5 GHz + 574 Mbps @ 2.4 GHz |
| Ethernet Port | 1 × 2.5 Gb RJ-45 (supports IEEE 802.3at PoE+) | Optional 12 V DC input |
| Antenna | Internal omni-directional: 2.4 GHz (2 × 4 dBi), 5 GHz (4 × 5 dBi) |
| Bluetooth | Bluetooth 5.2 |
| Mounting | Ceiling or wall (kits included) |
| Coverage Area | ≈ 140 m² (1500 ft²) |
| Concurrent Clients | 250+ devices |
| Key Wireless Features | 1024-QAM, OFDMA, MU-MIMO, HE160 (160 MHz), OFDM symbol ×4 length, band steering, airtime fairness, beamforming, seamless roaming, Omada Mesh, multiple SSIDs (up to 16), QoS/WMM, load balancing, rate limiting, auto channel assignment, power control, reboot/wireless scheduling, wireless stats |
| Wireless Security | Captive portal (voucher/SMS), WPA‑Personal/Enterprise, WPA2, WPA3, 802.1X, MAC filtering, access control, client isolation, VLAN per SSID, rogue AP detection |
| Transmit Power | CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz bands 1‑2), <30 dBm (5 GHz band 3); FCC: <25 dBm (2.4 GHz), <28 dBm (5 GHz) |
| Management | Omada App, Hardware Controllers (OC200/OC300), Software Controller, Cloud-Based, email alerts, LED control, MAC access control, SNMP v1/2c/3, syslog, SSH, HTTP/HTTPS, L3, multi-site, VLAN, zero-touch provisioning |
| Power Consumption | EU: 20.8 W | US: 22.3 W |
| Dimensions | 220 × 220 × 32.5 mm (8.7 × 8.7 × 1.3 in) |
| Environmental Specs | Operating: 0–40 °C, 10–90 % RH; Storage: –40–70 °C, 5–90 % RH (non-condensing) |
| Certifications | CE, FCC, RoHS |
| Package Includes | EAP673 unit, ceiling/wall mounting kits, installation guide |
The EAP673 is a business-grade, ceiling- or wall-mount Wi‑Fi 6 access point designed for environments like offices, hotels, retail, and meeting rooms. It delivers blazing-fast AX5400 dual-band speeds (up to 4804 Mbps on 5 GHz and 574 Mbps on 2.4 GHz), supports 160 MHz channels for peak performance, and integrates seamlessly into the Omada SDN for efficient centralized management. Powered via 802.3at PoE+ or optional DC adapter, it also features Bluetooth 5.2 for added flexibility.
SPECIFICATION
| Feature | Description |
|---|---|
| Wireless Standard | Wi‑Fi 6 (802.11ax), backward compatible with 802.11a/b/g/n/ac |
| Wi‑Fi Speeds | AX5400: 4804 Mbps @ 5 GHz + 574 Mbps @ 2.4 GHz |
| Ethernet Port | 1 × 2.5 Gb RJ-45 (supports IEEE 802.3at PoE+) | Optional 12 V DC input |
| Antenna | Internal omni-directional: 2.4 GHz (2 × 4 dBi), 5 GHz (4 × 5 dBi) |
| Bluetooth | Bluetooth 5.2 |
| Mounting | Ceiling or wall (kits included) |
| Coverage Area | ≈ 140 m² (1500 ft²) |
| Concurrent Clients | 250+ devices |
| Key Wireless Features | 1024-QAM, OFDMA, MU-MIMO, HE160 (160 MHz), OFDM symbol ×4 length, band steering, airtime fairness, beamforming, seamless roaming, Omada Mesh, multiple SSIDs (up to 16), QoS/WMM, load balancing, rate limiting, auto channel assignment, power control, reboot/wireless scheduling, wireless stats |
| Wireless Security | Captive portal (voucher/SMS), WPA‑Personal/Enterprise, WPA2, WPA3, 802.1X, MAC filtering, access control, client isolation, VLAN per SSID, rogue AP detection |
| Transmit Power | CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz bands 1‑2), <30 dBm (5 GHz band 3); FCC: <25 dBm (2.4 GHz), <28 dBm (5 GHz) |
| Management | Omada App, Hardware Controllers (OC200/OC300), Software Controller, Cloud-Based, email alerts, LED control, MAC access control, SNMP v1/2c/3, syslog, SSH, HTTP/HTTPS, L3, multi-site, VLAN, zero-touch provisioning |
| Power Consumption | EU: 20.8 W | US: 22.3 W |
| Dimensions | 220 × 220 × 32.5 mm (8.7 × 8.7 × 1.3 in) |
| Environmental Specs | Operating: 0–40 °C, 10–90 % RH; Storage: –40–70 °C, 5–90 % RH (non-condensing) |
| Certifications | CE, FCC, RoHS |
| Package Includes | EAP673 unit, ceiling/wall mounting kits, installation guide |
EAP673 - AX5400 Ceiling Mount Dual-Band Wi-Fi 6 Access Point
- Regular price
- $229.00
- Sale price
- $229.00
