About
The EAP660 HD is a ceiling-mounted Wi‑Fi 6 access point designed for high-density environments such as offices, schools, retail stores, and hotels. It delivers ultra-fast AX3600 speeds—up to 2402 Mbps on 5 GHz and 1148 Mbps on 2.4 GHz—optimized for high-performance multi-user environments. With advanced wireless technologies like OFDMA and MU-MIMO, it handles over 1,000 clients, providing strong, stable, and efficient wireless coverage. Integrated with TP-Link’s Omada SDN platform, it supports centralized cloud management, seamless roaming, and zero-touch provisioning, making it an ideal solution for scalable enterprise networks.
SPECIFICATION
| Feature | Description |
|---|---|
| Wireless Standard | Wi‑Fi 6 (IEEE 802.11ax), backward compatible with 802.11a/b/g/n/ac |
| Wi‑Fi Speeds | AX3600: Up to 2402 Mbps (5 GHz) + 1148 Mbps (2.4 GHz) |
| Ethernet Port | 1 × 2.5 Gbps Ethernet (RJ45) port with 802.3at PoE+; optional 12 V DC input |
| Antenna Type | Internal omni‑directional antennas: • 2.4 GHz: 4 × 4 dBi • 5 GHz: 4 × 5 dBi |
| Bluetooth | Bluetooth 5.2 (in V2 model) |
| Mounting | Ceiling or wall mount (kits included) |
| Coverage Area | Up to ~200 m² (~2150 ft²) |
| Concurrent Clients | 1,000+ devices supported |
| Advanced Wireless Features | 1024‑QAM, Long OFDM symbol, OFDMA, MU‑MIMO, 8 spatial streams, up to 16 SSIDs (8 per band), band steering, airtime fairness, beamforming, seamless roaming, Omada Mesh, load balancing, QoS (WMM), rate limiting, reboot/wireless scheduling, wireless stats |
| Security Features | Captive portal, WPA/WPA2/WPA3, 802.1X, MAC filtering, client isolation, VLAN per SSID, rogue AP detection |
| Transmit Power | CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz Bands 1/2), <28 dBm (5 GHz Band 3) FCC: <26 dBm (all bands) |
| Power Consumption | EU: ~18.5 W; US: ~21.5 W |
| Dimensions | V2: 220 × 220 × 32.5 mm V1: 243 × 243 × 64 mm |
| Management | Omada App, hardware/software/cloud controllers, centralized cloud management, SNMP, SSH, web UI (HTTP/HTTPS), MAC access control, LED control, email alerts, zero-touch provisioning, VLAN, multi-site support |
| Certifications | CE, FCC, RoHS |
| Package Contents | Access point unit, power adapter, mounting kits, installation guide |
| Environment | Operating: 0–40 °C, 10–90 % RH Storage: –40–70 °C, 5–90 % RH |
The EAP660 HD is a ceiling-mounted Wi‑Fi 6 access point designed for high-density environments such as offices, schools, retail stores, and hotels. It delivers ultra-fast AX3600 speeds—up to 2402 Mbps on 5 GHz and 1148 Mbps on 2.4 GHz—optimized for high-performance multi-user environments. With advanced wireless technologies like OFDMA and MU-MIMO, it handles over 1,000 clients, providing strong, stable, and efficient wireless coverage. Integrated with TP-Link’s Omada SDN platform, it supports centralized cloud management, seamless roaming, and zero-touch provisioning, making it an ideal solution for scalable enterprise networks.
SPECIFICATION
| Feature | Description |
|---|---|
| Wireless Standard | Wi‑Fi 6 (IEEE 802.11ax), backward compatible with 802.11a/b/g/n/ac |
| Wi‑Fi Speeds | AX3600: Up to 2402 Mbps (5 GHz) + 1148 Mbps (2.4 GHz) |
| Ethernet Port | 1 × 2.5 Gbps Ethernet (RJ45) port with 802.3at PoE+; optional 12 V DC input |
| Antenna Type | Internal omni‑directional antennas: • 2.4 GHz: 4 × 4 dBi • 5 GHz: 4 × 5 dBi |
| Bluetooth | Bluetooth 5.2 (in V2 model) |
| Mounting | Ceiling or wall mount (kits included) |
| Coverage Area | Up to ~200 m² (~2150 ft²) |
| Concurrent Clients | 1,000+ devices supported |
| Advanced Wireless Features | 1024‑QAM, Long OFDM symbol, OFDMA, MU‑MIMO, 8 spatial streams, up to 16 SSIDs (8 per band), band steering, airtime fairness, beamforming, seamless roaming, Omada Mesh, load balancing, QoS (WMM), rate limiting, reboot/wireless scheduling, wireless stats |
| Security Features | Captive portal, WPA/WPA2/WPA3, 802.1X, MAC filtering, client isolation, VLAN per SSID, rogue AP detection |
| Transmit Power | CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz Bands 1/2), <28 dBm (5 GHz Band 3) FCC: <26 dBm (all bands) |
| Power Consumption | EU: ~18.5 W; US: ~21.5 W |
| Dimensions | V2: 220 × 220 × 32.5 mm V1: 243 × 243 × 64 mm |
| Management | Omada App, hardware/software/cloud controllers, centralized cloud management, SNMP, SSH, web UI (HTTP/HTTPS), MAC access control, LED control, email alerts, zero-touch provisioning, VLAN, multi-site support |
| Certifications | CE, FCC, RoHS |
| Package Contents | Access point unit, power adapter, mounting kits, installation guide |
| Environment | Operating: 0–40 °C, 10–90 % RH Storage: –40–70 °C, 5–90 % RH |
EAP660 HD - AX3600 Ceiling Mount Dual-Band Wi-Fi 6 Access Point
- Regular price
- $399.00
- Sale price
- $399.00
