The EAP620 HD offers powerful AX1800 Wi‑Fi 6 performance with speeds up to 1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz. Designed for high-density environments, it provides up to 4× the device capacity compared to Wi‑Fi 5, making it ideal for venues like offices, classrooms, and conference spaces. The ultra-slim design (160 mm diameter × 33.6 mm thick) blends discreetly into interiors, while flexible power options (802.3at PoE+, passive PoE, or included DC adapter) simplify deployment. Rich wireless features include seamless roaming, band steering, airtime fairness, mesh support, and advanced security with WPA3 and captive portal options. It’s fully compatible with the Omada SDN ecosystem for streamlined, centralized management.
SPECIFICATION
Feature | Description |
---|---|
Wireless Standard | IEEE 802.11ax (Wi‑Fi 6), dual‑band |
Maximum Data Rate | 5 GHz: Up to 1201 Mbps; 2.4 GHz: Up to 574 Mbps (Total: ~1775 Mbps) |
Hardware Interface | 1× Gigabit Ethernet (supports 802.3at PoE+, passive PoE, and 12 V DC) |
Power Options | 802.3at PoE+, 48 V Passive PoE, 12 V / 1.5 A DC (adapter included) |
Power Consumption | EU: ~14.4 W (PoE) / ~13.1 W (DC); US: ~14.9 W (PoE) / ~13.4 W (DC) |
Antennas | Internal omni‑directional: 2.4 GHz – 2× 4 dBi; 5 GHz – 2× 5 dBi |
Mounting | Ceiling / Wall / Junction Box (mounting kits included) |
Coverage Area | Approximately 140 m² (~1,500 ft²) |
Concurrent Clients | Supports ~1,020+ devices |
Wireless Features | 1024‑QAM, Longer OFDM Symbol, OFDMA, MU‑MIMO, up to 16 SSIDs, band steering, load balancing, airtime fairness, beamforming, automatic channel assignment, transmit power control, QoS (WMM), rate limiting, wireless statistics, scheduling, mesh, seamless roaming |
Security | Captive portal, access control, MAC filtering, client isolation, SSID‑to‑VLAN mapping, rogue AP detection, 802.1X, WEP, WPA/WPA2/WPA3 (Personal & Enterprise) |
Transmit Power | CE: < 20 dBm (2.4 GHz), < 23–25 dBm (5 GHz); FCC: < 25 dBm (both bands) |
Management | Omada App, Cloud / Hardware / Software Controllers, SNMP v1/v2c/v3, syslog, SSH, web interface, multi-site support, management VLAN, email alerts, LED control, zero‑touch provisioning |
Certifications | CE, FCC, RoHS |
Package Contents | EAP620 HD unit, power adapter, mounting kits, installation guide |
System Requirements | Windows XP–11, Linux |
Operating Conditions | 0–40 °C; humidity 10–90% RH (non‑condensing) |
Storage Conditions | −40–70 °C; humidity 5–90% RH (non‑condensing) |
