The Draytek Vigor 2767 35b is a robust VDSL2/ADSL2+ modem router designed for small to medium businesses and demanding home users. Featuring dual WAN connectivity, it supports simultaneous broadband connections for enhanced redundancy and load balancing. The device delivers reliable performance with built-in firewall protection, VPN capabilities, and comprehensive management tools. With multiple Gigabit Ethernet ports and wireless connectivity, it provides flexible network expansion options. The Vigor 2767 35b is ideal for users requiring stable, secure connectivity with advanced routing features and failover support for uninterrupted internet access.





KEY FEATURES

  • Ready to connect to NTD (Network Termination Device) of NBN (Aust) and UFB (NZ)
  • 1 x VDSL2 35b/ADSL2+ WAN port
  • 35b Supervectoring VDSL2
  • 1 x configurable 2.5 GbE WAN/LAN port (P1)
  • 3 x Gigabit LAN ports with 50,000 NAT sessions
  • NAT throughput with Hardware Acceleration over 2.3 Gbps
  • IPsec VPN throughput up to 390 Mbps (AES 256 bits)
  • Object-based SPI Firewall, Content Security Management (CSM), URL/IP Reputation and Port Knocking
  • IAM (Identity and Access Management) to enhance security management and user experience
  • IPv6 & IPv4
  • 16 x VPN tunnels, including IPsec, OpenVPN, and WireGuard, with EasyVPN features that simplify VPN setup for effortless connectivity
  • 2 x USB ports for 4G Backup, FTP server, network printer or thermometer
  • Virtual Switch Controller to manage up to 5 VigorSwitches
  • Supports VigorACS 3 Central Management Software for remote management
  • 2 years back to base warranty





SPECIFICATION

Performance
NAT Session 50,000
Max. NAT (Mbps) 2300
WAN
xDSL 1
Selectable Gigabit WAN/LAN 1 x 2.5 GbE
VDSL Standards ITU-T G.993.1 (VDSL), ITU-T G.993.2 Annex A/B/M/Q, G.997.1
VDSL2 Profile 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a, 35b
ADSL Standards ITU-T G.992.1(G.dmt), T1.413 Issue 2
Band Plan 998, 997
Cellular (via USB) 2
Wireless WAN (2.4GHz + 5GHz) (ax model only)
Internet Connection
IPv4 PPPoE, DHCP, Static IP
IPv6 PPP, DHCPv6, Static IPv6, TSPC, 6rd, 6in4 Static Tunnel
802.1p/q Multi-VLAN Tagging
Failover
Connection Detection ARP, Ping
WAN Data Budget
Dynamic DNS
DrayDDNS
LAN
Fixed LAN (RJ-45, GbE) 3
LAN Subnet 4
VLAN 802.1q Tag-based VLAN
Max. Number of VLAN 8
DHCP Server Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
Wired 802.1x Authentication
Port Mirroring
Local DNS Server
Conditional DNS Forwarding
Hotspot Web Portal (Profile No.) 2
Hotspot Authentication Click-Through, Social Login, SMS PIN, RADIUS, External Portal Server
Other Ports
USB 2
USB Type 2.0
USB Application User Management, File Explorer, FTP File Sharing, Device Status, Printer Server, Temperature Sensor, USB WAN
SMB File Sharing
(Requires external storage)
Networking
Routing IPv4 Static Routing, IPv6 Static Routing, Policy Route, Inter-VLAN Route,
RIP v1/v2, OSPF(V2/V3), BGP
Policy-based Routing Protocol, IP Address, Port
DNS Security (DNSSEC)
IGMP IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave
Local RADIUS server
Bandwidth Management
Traffic Shaping Policy
IP-based Bandwidth Limit
IP-based Session Limit
QoS (Quality of Service) IP Address, Port, Application
APP QoS
Default Policy
VoIP Prioritization
NAT
Port Forwarding
DMZ Host
Port Trigger
ALG (Application Layer Gateway) SIP, RTSP, FTP, H.323
UPnP
Management
Local Service HTTP, HTTPS, Telnet, SSHv2, FTP, TR-069
Config Backup/Restore
Firmware Upgrade WUI, TFTP, TR-069
Role-based Privilege
Access Control Access List, Brute Force Protection
Notification Alert SMS, E-mail
SNMP v1, v2c, v3
Syslog
Virtual AP Controller (Device up to) 20
Mesh (Number of manageable APs) 7 (ax model only)
Virtual Switch Controller 5
Managed by VigorACS Since f/w v5.3.5
Security
URL/IP Reputation
Firewall Filter IP, Content, Traffic
Port Knocking
Defense Setup ARP Spoofing, IP Spoofing
MAC Filtering Profile
IPv6 Address Security
IAM
Users & Groups
Access Policies
Group Policies
Conditional Access Policy
Resources
Account Status
Backup and Restore
VPN
Site-to-Site VPN
Teleworker VPN
EasyVPN
Protocols IPsec, IKEv1/IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN, WireGuard
Max. VPN Tunnels 16
IPsec VPN Throughput (AES 256 bits) 300 Mbps (single-directional)
WireGuard VPN Throughput 50 Mbps (single-directional)
User Authentication Local, RADIUS, TACACS+, mOTP, TOTP
IKE Authentication Pre-Shared Key, X.509
IPsec Authentication SHA-1, SHA-256
Encryption DES, 3DES, AES
Single-Armed VPN
NAT-Traversal (NAT-T)
VPN Connection Status
Backup & Restore
Monitoring
Clients List
Log Center
Wireless Information (ax model only)
WAN
ARP Table
Route Table
DHCP Table
IPv6 TSPC Status
IPv6 Neighbor Table
LLDP Neighbors
DNS Cache Table
DSL Status
Remote DSL Status
PPPoE Pass-Through
Session Table
Running Service
Port Knocking Status
Physical
Power Supply Vigor2767: DC 12V @ 1.15A
Vigor2767ax: DC 12V @ 1.8A
Max. Power Consumption Vigor2767: 13.7 watts
Vigor2767ax: 21.6 watts
Dimension 207mm x 131mm x 42mm
Weight Vigor2767: 460g
Vigor2767ax: 510g
Operating Temperature 0 to 45°C
Storage Temperature -25 to 70°C
Operating Humidity (non-condensing) 10 to 90%



Note :
  • All specifications are subject to change without notice.
  • The throughput figures are maximum, based on DrayTek internal testing with optimal conditions. The actual performance may vary depending on the different network conditions and applications activated.
