About
Learn what makes this product unique and why it’s right for you.
TP-Link TL-SG1005P is a 5-port Gigabit desktop switch with 4 PoE+ ports, designed to provide both data connectivity and power over a single Ethernet cable to devices such as IP cameras, wireless access points, and VoIP phones. It offers plug-and-play installation, a durable metal housing, and intelligent PoE management for reliable operation.
SPECIFICATION
| HARDWARE FEATURES | |
|---|---|
| Interface | • 5× 10/100/1000Mbps RJ45 Ports • AUTO Negotiation • AUTO MDI/MDIX |
| Network Media | * 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity | Fanless |
| External Power Supply | External Power Adapter(Output: 48VDC / 1.25A) |
| Packet Forwarding Rate | 7.44 Mpps |
| PoE Ports (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–4 • Power Supply: 65 W |
| Mac Address Table | 4K |
| Jumbo Frame | V5: 16 KB V6: 9 KB |
| Switching Capacity | 10 Gbps |
| Dimensions ( W x D x H ) | 3.9×3.9×1.0 in (99.8×98×25 mm) |
| Max. Power Consumption | V5: • 3.44 W (220/50 Hz. no PD connected) • 74.49 W (220/50 Hz. with 65 W PD connected) V6: • 3.44 W (220/50 Hz. no PD connected) • 74.88 W (220/50 Hz. with 65 W PD connected) |
| Max. Heat Dissipation | • 11.73 BTU/h (no PD connected) • 254.01 BTU/h (with 65 W PD connected) |
| SOFTWARE FEATURES | |
|---|---|
| Advanced Features | • Compatible With IEEE 802.3af/at Compliant PDs • Mac Address Auto-Learning And Auto-Aging • IEEE 802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping • Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission) • PoE Auto Recovery (Ports 1-4) |
| Transmission Method | Store-And-Forward |
| OTHERS | |
|---|---|
| Certification | FCC, CE, RoHS |
| Package Content | • TL-SG1005P • Power Adapter • Installation Guide • Power Cord • Rubber Feet |
| Environment | Operating Temperature: -5–40 ℃ (23–104 ℉); Storage Temperature: -40–70 ℃ (-40–158 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing |
Learn what makes this product unique and why it’s right for you.
TP-Link TL-SG1005P is a 5-port Gigabit desktop switch with 4 PoE+ ports, designed to provide both data connectivity and power over a single Ethernet cable to devices such as IP cameras, wireless access points, and VoIP phones. It offers plug-and-play installation, a durable metal housing, and intelligent PoE management for reliable operation.
SPECIFICATION
| HARDWARE FEATURES | |
|---|---|
| Interface | • 5× 10/100/1000Mbps RJ45 Ports • AUTO Negotiation • AUTO MDI/MDIX |
| Network Media | * 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity | Fanless |
| External Power Supply | External Power Adapter(Output: 48VDC / 1.25A) |
| Packet Forwarding Rate | 7.44 Mpps |
| PoE Ports (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–4 • Power Supply: 65 W |
| Mac Address Table | 4K |
| Jumbo Frame | V5: 16 KB V6: 9 KB |
| Switching Capacity | 10 Gbps |
| Dimensions ( W x D x H ) | 3.9×3.9×1.0 in (99.8×98×25 mm) |
| Max. Power Consumption | V5: • 3.44 W (220/50 Hz. no PD connected) • 74.49 W (220/50 Hz. with 65 W PD connected) V6: • 3.44 W (220/50 Hz. no PD connected) • 74.88 W (220/50 Hz. with 65 W PD connected) |
| Max. Heat Dissipation | • 11.73 BTU/h (no PD connected) • 254.01 BTU/h (with 65 W PD connected) |
| SOFTWARE FEATURES | |
|---|---|
| Advanced Features | • Compatible With IEEE 802.3af/at Compliant PDs • Mac Address Auto-Learning And Auto-Aging • IEEE 802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping • Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission) • PoE Auto Recovery (Ports 1-4) |
| Transmission Method | Store-And-Forward |
| OTHERS | |
|---|---|
| Certification | FCC, CE, RoHS |
| Package Content | • TL-SG1005P • Power Adapter • Installation Guide • Power Cord • Rubber Feet |
| Environment | Operating Temperature: -5–40 ℃ (23–104 ℉); Storage Temperature: -40–70 ℃ (-40–158 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing |
TP-Link 5-Port Gigabit Desktop Switch with 4-Port PoE Unmanaged (TL-SG1005P)
- Regular price
- $90.00
- Sale price
- $90.00
- Regular price
-
SKU: TL-SG1005P
Couldn't load pickup availability
